446 Stainless Steel Tubes & Pipes | Premium Durability
446 Stainless Steel Tubes & Pipes | Premium Durability
Couldn't load pickup availability
Product Detail Page: 446 Stainless Steel Tubes & Pipes | Premium Durability
Technical Specifications & Properties
(Structured Tables for Clarity and SEO Optimization)
1. Dimensional Specifications
| Parameter | Range | Standards |
|---|---|---|
| Outer Diameter (OD) | 12.7mm – 1016mm | ASTM A312, ASME SA312, EN 10216 |
| Wall Thickness | 0.4mm – 30mm | Schedule 5S to XXH |
| Length | 1m – 12m (Standard) / Custom Cut Lengths | ISO 1127, ASME SA312 |
| Shape | Round, Square, Rectangular, Oval | ASTM A554, ASTM A269 |
Notes:
- Customizable 446 stainless steel tubes & pipes are available for specialized projects, including thin-walled (0.4mm) and thick-walled (up to 30mm) designs.
- Tolerance: ±0.1% for precision applications.
2. Material Properties
| Grade | Hardness (HV) | Yield Strength (MPa) | Tensile Strength (MPa) |
|---|---|---|---|
| 446 Stainless Steel | 167 – 250 | ≥335 | ≥515 |
| 304/304L | 170 – 200 | ≥205 | ≥515 |
| 316L | 180 – 220 | ≥215 | ≥520 |
Source: ASTM A312, EN 10088-3.
3. Manufacturing Processes
| Process | Applications | Advantages |
|---|---|---|
| Seamless | High-pressure systems, boilers, heat exchangers | Superior corrosion resistance; no weld seams |
| Welded (ERW/EFW) | Structural, low-pressure fluid transport | Cost-effective; rapid production |
| Cold Rolled | Precision instruments, medical devices | Smooth surface; tight dimensional control |
| Hot Finished | Large-diameter industrial pipelines | High-temperature stability (up to 1082°C) |
Compliance: ASME, PED, TUV, and NACE certifications.
Detailed Technical Descriptions
1. Tensile & Bend Strength
446 stainless steel tubes & pipes exhibit exceptional mechanical performance, with a tensile strength of ≥515 MPa and yield strength of ≥335 MPa. This makes them ideal for high-stress environments like combustion chambers and industrial boilers. The bend strength is enhanced through controlled annealing processes, ensuring structural integrity even under cyclic loading.
2. Weight Calculation
Use the formula below to estimate pipe weight per meter:
Weight (kg/m) = (OD – Wall Thickness) × Wall Thickness × 0.02466
Example: A 50mm OD pipe with 2mm wall thickness weighs ≈2.42 kg/m.
3. Identification Marking
All products are laser-etched with:
- Grade (e.g., 446, 304L)
- Size (OD × Wall Thickness × Length)
- Certification (ASTM/EN Standard, Heat Number)
- Manufacturer Logo
This ensures traceability and compliance with international standards.
4. Causes of Stainless Steel Corrosion
Despite inherent rust resistance, corrosion in 446 stainless steel tubes & pipes may occur due to:
- Chloride Exposure: Prolonged contact with seawater or de-icing salts can cause pitting.
- Galvanic Corrosion: Avoid pairing with dissimilar metals in humid environments.
- High-Temperature Oxidation: While 446 steel resists scaling up to 1082°C, extreme thermal cycling may degrade protective oxide layers.
Humanized Design & Custom Solutions
Our humanized design stainless steel pipes and tubes prioritize user convenience and safety:
- Ergonomic Connectors: Pre-insulated joints reduce installation time by 30%.
- Surface Finishes: Options include polished, electropolished, or sandblasted surfaces for aesthetic and functional needs.
- Custom Packaging: Wooden crates or foam-lined bundles prevent transit damage.
Why Choose Our Stainless Steel Solutions?
(Positioned at the Bottom for SEO Prioritization of Technical Content)
- Global Manufacturer Network: As leading stainless steel pipe tube manufacturers, we maintain 10,000+ tons of ready-to-ship inventory across 20+ grades.
- Tailored Customization: Adapt 446 stainless steel tubes & pipes to your project’s needs—no minimum order quantity.
- Quality Assurance: Raw materials sourced from top mills (e.g., Tsingshan, Acerinox) with 100% spectrographic testing.
- Fast Delivery: 72-hour dispatch for standard sizes; global logistics partnerships ensure on-time delivery.
- Sustainability: 70% recycled content; ISO 14001-certified production.
