Durable Stainless Steel Metal Rods – 202/304/316 Thin-Walled Welded Pipes

Durable Stainless Steel Metal Rods – 202/304/316 Thin-Walled Welded Pipes

$1,650.00 SGD
$1,650.00 SGD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity
Dimensions

Product Detail Page: ​Durable Stainless Steel Metal Rods & 202/304/316 Thin-Walled Welded Pipes

​Specifications & Technical Data

Comprehensive specifications for ​stainless steel metal rods and welded pipes, designed for industrial and commercial applications.

​Property ​Grade 202 ​Grade 304 ​Grade 316
​Material Standard ASTM A276, AISI 202 ASTM A312, AISI 304 ASTM A312, AISI 316
​Chemical Composition 17-19% Cr, 4-6% Ni 18-20% Cr, 8-10.5% Ni 16-18% Cr, 10-14% Ni, 2-3% Mo
​Tensile Strength (MPa) 620 515–685 485–620
​Yield Strength (MPa) 275 205–310 170–310
​Hardness (HBW) ≤250 ≤210 ≤217
​Outer Diameter (mm) 6–630 6–630 6–630
​Wall Thickness (mm) 0.5–12 0.5–12 0.5–12
​Length (m) 1–12 1–12 1–12
​Surface Finish Bright, Pickled Polished, Hairline Acid-Washed, Matte
​Processing Technique Cold Rolled, Welded Hot Rolled, Welded Seamless, Welded

​Key Performance Attributes

  1. ​Tensile Strength

    • ​Grade 202: Ideal for lightweight structural applications due to balanced strength (620 MPa) and ductility.
    • ​Grade 304: Combines moderate tensile strength (515–685 MPa) with exceptional corrosion resistance, suitable for food processing and architectural uses.
    • ​Grade 316: Enhanced with molybdenum for superior tensile performance (485–620 MPa) in chloride-rich environments like marine and chemical industries.

  2. ​Bending Strength

    • All grades exhibit excellent bendability due to low carbon content (<0.08%) and austenitic microstructure. ​Stainless steel metal rods maintain structural integrity even at 90° bends, minimizing cracking risks.

  3. ​Identification Marking

    • Laser-etched labels include:
      • ​Grade (e.g., 304L, 316L)
      • ​Standard (ASTM/AISI)
      • ​Heat Number for traceability
      • ​Size (OD × WT × Length)
    • Compliant with ISO 9443 and ASTM A480 specifications.

  4. ​Weight Calculation Formula

    • ​For Pipes: Weight (kg/m) = (OD – WT) × WT × 0.0248
    • ​For Rods: Weight (kg/m) = (π × (OD/2)²) × 7.93
    • Example: A 304 stainless steel pipe with 50mm OD and 2mm WT weighs ​2.35 kg/m.

  5. ​Stainless Steel Corrosion: Causes & Prevention

    • ​Chloride Exposure: Prolonged contact with seawater or de-icing salts accelerates pitting in non-molybdenum grades (e.g., 304).
    • ​Mechanical Damage: Scratches or improper handling disrupt the passive chromium oxide layer, leading to localized rust.
    • ​Thermal Stress: Excessive heat (e.g., welding without ​stainless steel tig rod) causes carbide precipitation, reducing corrosion resistance.
    • ​Prevention: Use ​stainless steel filler rod ER316L for welding, apply passivation treatments, and avoid abrasive cleaning tools.

​Why Choose Our Stainless Steel Products?

  1. ​Certified Quality

    • All ​stainless steel metal rods and pipes comply with ISO 9001, ASTM, and EN standards, validated by third-party inspections.

  2. ​Customization & Precision

    • Tailored solutions for OD (6–630mm), wall thickness (0.5–12mm), and surface finishes (mirror, brushed, etc.).

  3. ​Rapid Delivery

    • Ready stock for 200/300/400 series alloys, with bulk orders shipped globally in 7–15 days.

  4. ​Technical Support

    • 24/7 engineering assistance for welding (using ​stainless steel tig rod), corrosion management, and load calculations.

  5. ​Sustainability

    • 100% recyclable materials with low carbon footprint, aligning with green manufacturing goals.
