Eco-Friendly Stainless Steel Metal Plate | 06Cr18Ni11Ti & RoHS Compliant
Eco-Friendly Stainless Steel Metal Plate | 06Cr18Ni11Ti & RoHS Compliant
Couldn't load pickup availability
Eco-Friendly Stainless Steel Metal Plate | 06Cr18Ni11Ti & RoHS Compliant
Product Specifications
| Property | 06Cr18Ni11Ti (GB/T 1220-2007) | RoHS Compliance Standards |
|---|---|---|
| Thickness | 0.5–60 mm | 0.4–6 mm |
| Width | 1000–2500 mm | 1220–15000 mm |
| Length | Custom up to 6000 mm | 2000–6000 mm |
| Surface Finish | 2B, Mirror, HL, No.4 | Pickled, Annealed, BA |
| Hardness (HV) | ≤187 HBW | ≤200 HBW |
| Density | 7.93 g/cm³ | 7.85–7.93 g/cm³ |
| Operating Temp | -196°C to 900°C | -50°C to 550°C |
Mechanical Properties
Tensile Strength
The 06Cr18Ni11Ti stainless steel plate exhibits a minimum tensile strength of 520 MPa and a yield strength of ≥205 MPa. Its austenitic structure, enhanced by titanium (Ti), ensures exceptional resistance to stress corrosion cracking, making it ideal for stainless steel plate heat exchanger systems exposed to high-temperature fluids or aggressive media like chlorides.
Bending Strength
With ≥40% elongation in annealed conditions, this material supports seamless cold-forming processes such as deep drawing and roll bending. Its ductility minimizes cracking risks during fabrication of custom stainless steel plates for architectural or industrial applications.
Identification & Marking
- Standard Markings:
- GB/T: 06Cr18Ni11Ti
- AISI: 321 (equivalent)
- EN: 1.4541
- Surface Marking: Laser-etched with grade, thickness, and batch number for full traceability.
Weight Calculation
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.93 g/cm³)
Example: A 10mm × 1.5m × 3m plate weighs 357.3 kg (10×1.5×3×7.93).
Why Stainless Steel Corrodes?
Despite its superior corrosion resistance, 06Cr18Ni11Ti may rust under extreme conditions:
- Chloride Exposure: Chlorides (e.g., seawater, industrial salts) penetrate the chromium oxide layer, causing localized pitting.
- Intergranular Corrosion: Prolonged exposure to 450–850°C triggers chromium carbide formation at grain boundaries, reducing corrosion resistance.
- Galvanic Corrosion: Contact with dissimilar metals (e.g., carbon steel) in humid environments accelerates electrochemical degradation.
- Mechanical Damage: Improper handling or abrasive tools can scratch the surface, exposing the base metal to oxidation.
Key Features & Applications
Material Advantages
- Corrosion Resistance: Titanium (Ti) stabilizes the alloy against sensitization, ideal for stainless steel divider plate systems in food processing or chemical plants.
- High-Temperature Stability: Retains structural integrity up to 900°C, suitable for boilers, exhaust systems, and heat treatment equipment.
- Hygienic Design: Non-porous 2B finish complies with FDA and EU hygiene standards for medical devices and pharmaceutical machinery.
Processing Techniques
| Process | Description |
|---|---|
| Cold Rolling | Enhances dimensional precision (±0.05mm) and surface uniformity. |
| Solution Treatment | Restores corrosion resistance by dissolving carbides at 1050–1100°C. |
| PVD Coating | Adds stainless steel divider plate aesthetics (e.g., black ion-plated finishes) for architectural panels. |
Comparative Insights
- stainless steel plate heat exchanger: Unlike carbon steel, 06Cr18Ni11Ti resists chloride-induced pitting, ensuring longevity in marine or chemical cooling systems.
- custom stainless steel plates: Tailored dimensions and finishes (e.g., mirror, brushed) meet niche requirements for luxury interiors or industrial equipment.
Why Choose Our Stainless Steel Plates?
- RoHS & REACH Compliance: Guaranteed absence of hazardous substances (Pb, Cd, Hg) for eco-sensitive applications.
- Customization Expertise: Laser cutting, embossing, and perforation services for custom stainless steel plates in aerospace, automotive, and construction.
- Global Certifications: ISO 9001, SGS, and TUV-certified production with full material traceability.
- Technical Support: 24/7 engineering guidance on welding, machining, and corrosion prevention.
- Sustainable Practices: 100% recyclable material with energy-efficient manufacturing processes.
