Eco-Friendly stainless steel plate | Recyclable & Non-Toxic Material Choices

Eco-Friendly stainless steel plate | Recyclable & Non-Toxic Material Choices

$1,096.00 SGD
$1,096.00 SGD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity

Eco-Friendly Stainless Steel Plate | Recyclable & Non-Toxic Material Choices

Product Specifications

Attribute Details
Material Grade 304, 316, 430 (ASTM A240/A480 compliant)
Thickness 0.3mm – 50mm (Customizable)
Width 1000mm – 2000mm
Length 2000mm – 6000mm
Surface Finish 2B (Cold Rolled), No.4 (Brushed), BA (Bright Annealed), Mirror Polish
Hardness HRB 80-95 (Annealed), HRC 20-35 (Cold Rolled)
Density 7.93 g/cm³ (304 Stainless Steel)

Key Features & Benefits

  1. Recyclable & Non-Toxic
    Made from 60-70% recycled content, our stainless steel plate meets global environmental standards. Free from harmful coatings, it ensures safety in food processing and medical applications.

  2. Superior Corrosion Resistance
    Outperforms zinc plated vs stainless steel in harsh environments. Chromium oxide layers prevent rust, making it ideal for marine and industrial use.

  3. High Strength & Durability

    • Tensile Strength: 520-860 MPa (varies by grade) .
    • Yield Strength: 210-310 MPa (304 grade).

  4. Customizable Dimensions
    Available in stainless steel 2 sections plate configurations for structural and architectural applications.

Technical Details

1. Tensile Strength

Tensile strength measures the maximum stress a material can withstand before breaking. For our plate stainless steel, this is tested via direct tensile methods per ASTM E8 standards. Results show consistent performance across grades:



  • 304 Stainless Steel: 515 MPa (min)
  • 316 Stainless Steel: 580 MPa (min)
  • 430 Stainless Steel: 450 MPa (min)

2. Bend Strength

Bend strength is critical for structural integrity. Our plates undergo three-point bending tests (ASTM E290), with results showing:



  • Cold Rolled Plates: Withstand bending angles up to 180° without cracking.
  • Annealed Plates: Higher ductility, suitable for complex forming.

3. Identification & Marking

  • ASTM Standards: Laser-etched markings (e.g., "304," "316") for traceability.
  • Heat Numbers: Unique batch codes for quality control.
  • Surface Finish Codes: e.g., "2B" for cold-rolled, "No.4" for brushed.

4. Weight Calculation

Use the formula:
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.93)
Example: A 3mm × 1m × 2m plate weighs 47.58 kg.

5. Why Stainless Steel Can Rust?

While stainless steel resists corrosion, improper use or maintenance may cause rust due to:

  • Chloride Exposure: Coastal or de-icing salt environments.
  • Mechanical Damage: Scratches or abrasions disrupting the passive layer.
  • Low-Quality Alloys: Subpar chromium/nickel content in inferior grades.

Comparison: Zinc Plated vs Stainless Steel

Feature Zinc Plated Steel Stainless Steel
Corrosion Resistance Moderate (prone to white rust) Exceptional (chromium oxide layer)
Lifespan 10-20 years (depending on coating) 50+ years (with minimal maintenance)
Cost Lower upfront cost Higher initial cost, lower lifecycle cost
Applications Temporary structures, fasteners Permanent installations, harsh environments

Why Choose Our Stainless Steel Plates?

  1. Certified Quality: Compliant with ASTM, EN, and JIS standards.
  2. Eco-Conscious Production: 100% recyclable, zero VOC emissions.
  3. Custom Solutions: Tailored dimensions, finishes, and grades.
  4. Global Support: Fast shipping, technical guidance, and after-sales service.
