Heat-Resistant Stainless Steel Metal Plate | 316L for High-Temperature Use
Product Specifications
| Property | 316L (AISI/UNS S31603) | EN Standards (1.4404) |
|---|---|---|
| Thickness | 0.1–120 mm | 0.4–60 mm |
| Width | 100–2200 mm | 1000–2400 mm |
| Length | Custom up to 12,000 mm | 2000–6000 mm |
| Surface Finish | 2B, BA, HL, Mirror, No.4 | Pickled, Annealed, Brushed |
| Hardness (HV) | ≤187 HBW | ≤200 HBW |
| Density | 7.93 g/cm³ | 7.85–7.93 g/cm³ |
| Operating Temp | -196°C to 900°C | -50°C to 550°C |
Mechanical Properties
Tensile Strength
The 316L stainless steel plate offers a minimum tensile strength of 520 MPa and a yield strength of ≥205 MPa. Its low-carbon composition (≤0.03% C) prevents carbide precipitation during welding, ensuring structural integrity in high-temperature environments like industrial furnaces or exhaust systems. This makes it ideal for stainless steel grill plate applications, where thermal cycling and mechanical stress are common.
Bending Strength
With ≥40% elongation in annealed conditions, 316L supports seamless cold-forming processes such as deep drawing and roll bending. Its austenitic microstructure resists deformation even at elevated temperatures, enabling precise fabrication of camping stainless steel plates or complex geometries for chemical reactors.
Identification & Marking
- Standard Markings:
- AISI/UNS: S31603
- EN: 1.4404
- GB/T: 022Cr17Ni12Mo2
- Surface Marking: Laser-etched or stamped with grade, thickness, heat number, and RoHS compliance for full traceability.
Weight Calculation
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.93 g/cm³)
Example: A 3mm × 1.2m × 2.4m plate weighs 68.7 kg (3×1.2×2.4×7.93).
Why Stainless Steel Corrodes?
Despite its exceptional corrosion resistance, 316L may rust under extreme conditions:
- Chloride Exposure: Chlorides (e.g., seawater, road salts) penetrate the chromium oxide layer, causing pitting corrosion.
- Intergranular Corrosion: Prolonged exposure to 450–850°C triggers chromium carbide formation at grain boundaries, reducing corrosion resistance.
- Galvanic Corrosion: Contact with dissimilar metals (e.g., carbon steel) in humid environments accelerates electrochemical degradation.
- Mechanical Damage: Abrasive tools or improper handling can scratch the surface, exposing the base metal to oxidation.
Key Features & Applications
Material Advantages
- Heat Resistance: Retains strength up to 900°C, ideal for stainless steel plate covers in boilers or heat exchangers.
- Corrosion Resistance: Molybdenum (2–3%) enhances resistance to chlorides and acids, suitable for marine or chemical processing.
- Hygienic Design: Non-porous 2B finish meets FDA standards for food-grade camping stainless steel plates.
Processing Techniques
| Process | Description |
|---|---|
| Cold Rolling | Achieves ±0.05mm precision for aerospace components. |
| Solution Annealing | Dissolves carbides at 1050–1100°C to restore corrosion resistance. |
| PVD Coating | Enhances stainless steel grill plate aesthetics with black ion-plated finishes. |
Comparative Insights
- stainless steel grill plate: Unlike carbon steel, 316L resists high-temperature oxidation and grease buildup, ensuring longevity in BBQ or commercial kitchen use.
- camping stainless steel plates: Lightweight and dishwasher-safe, these plates outperform plastic alternatives in durability and eco-friendliness.
- stainless steel plate covers: Custom-cut covers protect pipelines or machinery from corrosion and UV damage in industrial settings.
Why Choose Our 316L Stainless Steel Plates?
- Certified Excellence: Compliant with ASTM A240, EN 10088, ISO 9001, and RoHS.
- Global Inventory: 50,000+ tons of ready stock for rapid delivery to 30+ countries.
- Custom Solutions: Tailored dimensions (e.g., 4x8 FT sheets), perforations, and embossing for niche applications.
- Technical Support: 24/7 guidance on welding, machining (using the best drill bit for stainless steel plate), and corrosion prevention.
- Sustainability: 100% recyclable material with energy-efficient production.
