High-Performance Stainless Steel Metal Plate | 06Cr19Ni10 Grade

High-Performance Stainless Steel Metal Plate | 06Cr19Ni10 Grade

$1,480.00 SGD
$1,480.00 SGD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity

High-Performance Stainless Steel Metal Plate | 06Cr19Ni10 Grade

Technical Specifications

Parameter Details
Material Grade 06Cr19Ni10 (Equivalent to ASTM 304 / EN 1.4301)
Thickness Range 0.4 mm – 25 mm (Customizable for round stainless steel plate designs)
Hardness (Surface) HRB 70–90 (Annealed State); HRC ≤20 (Cold-Worked State)
Dimensions Width: 1000–4500 mm; Length: Custom-cut up to 12,000 mm
Tensile Strength 520–720 MPa
Yield Strength ≥205 MPa (Minimum)
Elongation ≥40% (Post-Annealing)
Surface Finish 2B (Smooth Matte), No. 4 (Brushed), BA (Bright Annealed), Silver Plated Stainless Steel
Weight Formula Weight (kg) = Thickness (mm) × Area (m²) × 7.93 (Density in g/cm³)
Thermal Conductivity 16.3 W/m·K (100°C); 21.5 W/m·K (500°C)
Melting Point 1398–1454°C

Key Performance Attributes

1. Tensile & Bend Strength

The 06Cr19Ni10 grade exhibits exceptional tensile strength (520–720 MPa) due to its austenitic microstructure stabilized by 18–20% chromium and 8–11% nickel. This ensures resistance to deformation under heavy loads, making it ideal for structural applications like sandwich maker with stainless steel plates or industrial machinery. Bend strength, approximately 1.5× tensile strength (780–1080 MPa), allows for complex shaping without cracking.



2. Identification & Certification

  • ASTM Standards: Marked as UNS S30400 (304) with laser-etched or embossed identifiers.
  • EN Standards: Complies with EN 1.4301 for EU markets.
  • GB/T 1220-2007: Certified for chemical composition and mechanical properties in China.

3. Weight Calculation

Use the formula:

For example, a round stainless steel plate with a 10 mm thickness and 1 m² area weighs 79.3 kg.

4. Causes of Stainless Steel Rust

Despite its corrosion resistance, localized rust may occur due to:

  • Chloride Exposure: Coastal environments or de-icing salts degrade the passive chromium oxide layer.
  • Improper Heat Treatment: Lack of solid-solution treatment (1050–1150°C) reduces alloy homogeneity, increasing corrosion susceptibility.
  • Mechanical Damage: Scratches or welding defects expose the base metal to oxidation.

Material Advantages

Enhanced Durability

  • Austenitic Stability: High nickel content (8–11%) prevents martensitic transformation, maintaining ductility in sub-zero temperatures.
  • Corrosion Resistance: Chromium forms a self-healing oxide layer, ideal for silver plated stainless steel finishes in humid or acidic environments.

Precision Manufacturing

  • Cold Rolling: Achieves ±0.1 mm thickness tolerance for seamless integration into appliances or architectural grids.
  • Laser Cutting: Edge smoothness ≤Ra 1.6 μm for precision components.

Sustainability

  • 100% Recyclable: Reduces carbon footprint and lifecycle costs.

Why Choose Our 06Cr19Ni10 Stainless Steel?

  1. Superior Material Integrity

    • Dual-certified (ASTM 304 & GB/T 1220) with mill test reports for traceability.
    • Optional nitrogen-enriched variants (06Cr19Ni10N) for enhanced strength and pitting resistance.

  2. Customization Flexibility

    • Tailored dimensions for round stainless steel plate designs or curved architectural elements.
    • Brushed, mirror, or silver plated stainless steel finishes to match aesthetic requirements.

  3. Technical Expertise

    • Free consultation on load calculations, welding protocols, and corrosion prevention.

  4. Industry-Leading Warranty

    • 10-year warranty against material defects and premature corrosion.
