High-Quality Stainless Steel Metal Plate | S31600 for Construction
High-Quality Stainless Steel Metal Plate | S31600 for Construction
Couldn't load pickup availability
High-Quality Stainless Steel Metal Plate | S31600 for Construction
Product Overview
Our S31600 stainless steel plates are premium-grade austenitic stainless steel designed for demanding construction applications. With exceptional corrosion resistance, high strength, and durability, they are ideal for structural frameworks, marine environments, chemical processing, and architectural finishes. This product meets international standards (ASTM A240, EN 10088-2) and is available in customizable dimensions and surface finishes.
Technical Specifications
1. Chemical Composition
| Element | Content (%) |
|---|---|
| Carbon (C) | ≤0.08 |
| Chromium (Cr) | 16.0–18.0 |
| Nickel (Ni) | 10.0–14.0 |
| Molybdenum (Mo) | 2.00–3.00 |
| Manganese (Mn) | ≤2.00 |
| Silicon (Si) | ≤1.00 |
| Phosphorus (P) | ≤0.045 |
| Sulfur (S) | ≤0.030 |
Complies with ASTM A240, UNS S31600, and EN 1.4401 standards.
2. Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥520 MPa |
| Yield Strength (0.2% Offset) | ≥205 MPa |
| Elongation (%) | ≥40 |
| Hardness (Brinell) | ≤187 HB |
| Density | 7.98 g/cm³ |
3. Physical Properties
| Property | Value |
|---|---|
| Melting Point | 1375–1390°C |
| Thermal Conductivity | 16.2 W/m·K |
| Electrical Resistivity | 0.74 Ω·mm²/m |
| Coefficient of Thermal Expansion | 16 × 10⁻⁶/K (20–100°C) |
4. Available Dimensions & Surface Finishes
| Thickness (mm) | Width (mm) | Length (mm) | Surface Finish |
|---|---|---|---|
| 0.5–100 | 1000–2200 | Custom (up to 6000) | 2B, BA, No.4, HL, Mirror |
Custom sizes and edge treatments (mill edge, slit edge) available upon request.
Key Features & Applications
1. Superior Strength & Durability
- Tensile Strength: S31600 offers a minimum tensile strength of 520 MPa, ensuring structural integrity under heavy loads.
- Bend Strength: Excellent ductility allows cold forming and bending without cracking, making it ideal for stainless steel transom plate applications in architectural frameworks.
2. Corrosion Resistance
Resists pitting, crevice corrosion, and chloride stress corrosion cracking, perfect for stainless steel weir plates in marine and chemical environments.
3. Heat Resistance
Maintains mechanical stability up to 870°C, suitable for high-temperature industrial equipment.
4. Surface Options
Choose from polished, brushed, or embossed finishes for aesthetic or functional needs, such as stainless steel switch plate covers in electrical systems.
Performance Details
1. Weight Calculation
Calculate plate weight using:
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.98)
Example: A 10mm × 1.5m × 3m plate weighs 359.1 kg.
2. Marking & Identification
Plates are laser-etched with grade (S31600/316L), thickness, heat number, and certification (EN 10204/3.1).
3. Why Stainless Steel Rusts?
While S31600 is highly corrosion-resistant, rust can occur due to:
- Chloride Exposure: Prolonged contact with seawater or de-icing salts damages the passive chromium oxide layer.
- Mechanical Damage: Scratches or abrasions expose the iron substrate to oxidation.
- Low Oxygen Environments: Stagnant water or sludge inhibits oxide layer regeneration.
- Chemical Contamination: Acids or alkalis (e.g., industrial cleaners) accelerate corrosion.
Why Choose Our S31600 Stainless Steel Plates?
- Certified Quality: ISO 9001, ISO 14001, and ISO 45001 certified production.
- Custom Solutions: Tailored dimensions, finishes, and technical support for stainless steel weir plates, switch plates, and more.
- Global Compliance: Meets ASTM, EN, JIS, and ASME standards.
- Traceability: Full material traceability with Mill Test Certificates (MTC).
- Fortune 500 Trusted: Preferred supplier for major construction and industrial projects.
