High-Strength Stainless Steel Metal Plate | S31600 & HL Durability
High-Strength Stainless Steel Metal Plate | S31600 & HL Durability
Couldn't load pickup availability
High-Strength Stainless Steel Metal Plate | S31600 & HL Durability
Product Specifications
| Attribute | Details |
|---|---|
| Material Grades | S31600 (UNS S31600), stainless steel perforated plate (Custom patterns) |
| Thickness | 0.5mm–150mm (Customizable) |
| Width | 100mm–3000mm |
| Surface Finish | HL (Hairline), 2B, BA, Mirror (8K), No.4, Embossed, stainless steel plate for sale variants |
| Hardness (HV) | 150–200 (Annealed), 250–300 (Cold Rolled) |
| Tensile Strength | ≥520 MPa (S31600), ≥860 MPa (Cold-Rolled) |
| Yield Strength | ≥205 MPa (S31600) |
| Thermal Conductivity | 16.2–21.5 W/m·K |
| Operating Temperature | -50°C to 800°C (Short-term: 900°C) |
| Certifications | ASTM A240, ASME SA240, EN 1.4401, JIS SUS316, ISO 9001/14001 |
Technical Properties
Tensile & Bend Strength
Our S31600 stainless steel plate delivers exceptional tensile strength (≥520 MPa), making it ideal for structural applications in corrosive environments like marine or chemical processing. The addition of 2-3% molybdenum enhances chloride resistance, outperforming 304-grade steel in saltwater and acidic conditions. For bend strength, cold-rolled variants achieve up to 1.5x higher rigidity than annealed plates, perfect for load-bearing components like offshore platforms or heat exchangers.
Weight Calculation
Calculate weight per unit area using:
Example: A 5mm-thick stainless steel perforated plate with 20% open area weighs ~31.9 kg/m².
Identification Methods
- ASTM/EN Standards: Laser-etched codes (e.g., "S31600" for molybdenum-enriched grades).
- Surface Marking: QR codes linked to mill test reports for traceability.
Why Stainless Steel Rusts & Prevention
While stainless steel resists rust through its chromium oxide layer (≥16% Cr), specific conditions compromise protection:
- Chloride Exposure: Coastal or industrial environments accelerate pitting corrosion in S31600 if passivation is incomplete.
- Mechanical Damage: Scratches on HL finish surfaces expose the base metal to oxidation. Use non-abrasive cleaning tools.
- Galvanic Corrosion: Contact with dissimilar metals (e.g., carbon steel) triggers electrochemical degradation. Isolation pads are recommended.
- Organic Contaminants: Food acids or pollutants degrade the passive layer. Clean biweekly with pH-neutral solutions.
Applications
- Industrial: Heat exchangers, pressure vessels (S31600 for chloride-rich media).
- Architectural: Stainless steel perforated plate for façades, sunscreens, and soundproofing.
- Medical: Surgical tools and implants due to biocompatibility.
- Marine: Shipbuilding components with HL finish for anti-slip surfaces.
Competitive Pricing & Availability
Our stainless steel plate price ranges from 3,000/ton, offering 10–15% cost savings compared to market averages. Custom perforated patterns (round, diamond, hexagonal) are available with 5–7-day lead times.
Why Choose Our Stainless Steel Plates?
- Premium Quality: S31600 plates undergo PMI testing and dual-certification (316/316L) for chemical compliance.
- Custom Solutions: Tailored dimensions (e.g., stainless steel plate for sale with anti-fingerprint coatings).
- Fast Global Shipping: 90% of orders ship within 7 days, including perforated and embossed variants.
- Sustainability: 100% recyclable, ISO 14001-certified production.
- Lifetime Warranty: 15-year anti-corrosion guarantee for industrial applications.
Why Us?
With over two decades of expertise, we combine aerospace-grade precision with cost efficiency. Our S31600 plates are trusted by Fortune 500 companies for projects demanding unmatched durability and compliance. From HL-finished architectural marvels to perforated industrial filters, we deliver solutions that redefine longevity.
