High-Tolerance Stainless Steel Sheet: 1–6mm 310S/309S Plates
High-Tolerance Stainless Steel Sheet: 1–6mm 310S/309S Plates
Couldn't load pickup availability
High-Tolerance Stainless Steel Sheet: 1–6mm 310S/309S Plates
Product Overview
Our stainless steel sheet series offers premium 310S/309S alloy plates engineered for extreme environments. With a focus on high tolerance (±0.05mm thickness accuracy), these sheets excel in aerospace, chemical processing, and high-temperature industrial applications. Featuring stainless steel perforated sheet customization and Home Depot-compatible sizes, our products meet ASTM A240, ASME SB-409, and EN 10088-2 standards.
Technical Specifications
| Property | Details |
|---|---|
| Material | 310S/309S stainless steel sheet (24-26% Cr, 19-22% Ni) |
| Thickness & Size | 1–6mm thickness; Customizable dimensions up to 48"x120" (±1/16" tolerance) |
| Hardness (HV) | 150–200 HV (annealed state); ≤187 HB (cold-rolled) |
| Surface Finish | Mirror-polished (Ra ≤0.02μm), No.4 satin, or stainless steel perforated sheet (5–100mm holes) |
| Tensile Strength | ≥520 MPa (310S), ≥485 MPa (309S) |
| Thermal Resistance | Stable up to 1150°C (2100°F) continuous use |
| Certifications | ASTM A240, ASME SB-409, EN 10088-2, RoHS, and ISO 9001 |
Key Properties & Performance
Tensile and Bending Strength
The stainless steel sheet in 310S grade achieves a tensile strength of ≥520 MPa, while 309S plates maintain ≥485 MPa, ensuring resistance to deformation under extreme loads. This is critical for applications like furnace baffles and heat exchangers, where mechanical stress is constant. Bending strength is enhanced through cold-rolled processing, allowing sheets to withstand repeated flexing without cracking—ideal for sheet stainless steel Home Depot-ready fabrication projects.
Weight Calculation
Calculate plate weight using:
Example: A 1.2m x 2.4m x 6mm 310S sheet weighs:
Rust Prevention & Causes
Although stainless steel sheet is corrosion-resistant, rust may occur due to:
- Chloride Exposure: Prolonged contact with salt or acidic substances degrades the chromium oxide layer.
- Mechanical Damage: Scratches from abrasive tools expose the base metal to oxidation.
- Low Oxygen Environments: Stagnant moisture inhibits the self-repairing passive layer.
- Improper Welding: Carbon contamination during welding causes intergranular corrosion.
Manufacturing & Identification
Production Process
- Cold Rolling: Raw 310S/309S coils are precision-rolled to meet 1–6mm thickness specifications.
- Solution Annealing: Heat-treated at 1030–1180°C to restore ductility and corrosion resistance.
- Surface Treatment: Electrolytic polishing or perforation for stainless steel perforated sheet designs.
- Laser Marking: Each sheet includes grade (310S/309S), thickness, heat number, and compliance marks.
Applications
- Aerospace: Engine components and exhaust systems.
- Chemical Processing: Reactors and heat exchangers.
- Architecture: Sheet stainless steel Home Depot-compatible cladding and decorative panels.
- Energy: Boiler parts and turbine components.
Why Choose Our Stainless Steel Sheets?
- Superior Material Quality: Only 310S/309S stainless steel sheet alloys are used, ensuring unmatched oxidation resistance.
- Customization: Tailored stainless steel perforated sheet patterns and Home Depot-ready sizing.
- Certified Durability: Compliant with ASTM, ASME, and ISO standards for industrial reliability.
- Technical Support: 24/7 engineering assistance for welding, cutting, and installation.
- Global Logistics: Fast shipping to North America, Europe, and Asia with 15-day lead times.
