High-Traffic Plate Stainless Steel | ASTM-Certified Grid Plates for Export

Technical Specifications

Performance & Features

1. Tensile Strength

Our ASTM-certified machined stainless steel plate faqs series excels in high-traffic environments:

• Grade 304: Offers 515–700 MPa tensile strength, ideal for industrial flooring and structural supports in warehouses.
• Grade 316L: Provides 520–670 MPa with molybdenum-enhanced corrosion resistance, perfect for coastal infrastructure or chemical plants.
• Grade 2205 Duplex: Delivers 620–900 MPa, combining high strength with chloride resistance for offshore platforms.
  All grades comply with ASTM A240 and ISO 3506, validated by Mill Test Reports (MTRs).

2. Bending Strength

Engineered to withstand heavy loads and repeated stress:

• Thin plates (≤6 mm) achieve 180° bends without cracking (per GB/T 232-2010), critical for forming stainless steel backsplash plate edges.
• Thick plates (>10 mm) require controlled radii (≥3× thickness) to prevent fractures in load-bearing frameworks like conveyor systems.

3. Identification & Marking

Each plate includes laser-etched identifiers for traceability:

• Grade designation (e.g., SUS304, 316L, 2205).
• Batch number, ASTM certification mark, and heat treatment code for compliance tracking.
  Custom square stainless steel plates may include QR codes for real-time quality verification.

4. Weight Calculation

Use the formula for precise engineering designs:
$\text{Weight (kg)}=\text{Thickness (mm)}\times \text{Width (m)}\times \text{Length (m)}\times 7.93(\text{Density})$
Example: A 1/4 in stainless steel plate (6.35 mm × 1.5 m × 3 m) weighs 226 kg – optimized for heavy-duty flooring or stainless steel backsplash plate systems.

5. Why Stainless Steel Can Rust?

Even high-grade stainless steel may degrade under specific conditions:

• Chloride Exposure: Coastal environments or de-icing salts induce pitting in 304-grade steel.
• Mechanical Damage: Scratches from heavy machinery disrupt the chromium oxide layer, necessitating electropolished finishes for machined stainless steel plate faqs hygiene.
• Intergranular Corrosion: Improper welding in 316L reduces molybdenum’s chloride resistance, requiring post-weld annealing.
  Preventative measures include regular cleaning with pH-neutral solutions and avoiding galvanic coupling with carbon steel.

Applications

• Industrial Flooring: High-traffic warehouse floors, chemical plant walkways (square stainless steel plates).
• Architectural: Stainless steel backsplash plate for commercial kitchens, corrosion-resistant facades.
• Marine: Offshore platforms, ship decking (2205 duplex grade).
• Custom Fabrication: Machined stainless steel plate faqs for machinery guards, conveyor components.

Why Choose Our ASTM-Certified Stainless Steel Plates?

1. ASTM Compliance: Rigorous adherence to ASTM A240 and ISO 3506 ensures global acceptance and safety.
2. Superior Durability: Grades like 316L and 2205 resist corrosion in extreme environments, outperforming chrome plated vs stainless steel hybrids.
3. Custom Solutions: Precision laser cutting (±0.1 mm tolerance) for complex square stainless steel plates designs.
4. Full Traceability: MTRs and QR-coded batch tracking guarantee material authenticity.
5. Sustainability: 100% recyclable with low-VOC production processes.
