Product Specifications

Key Properties

1. Tensile Strength

   • 06Cr18Ni11Ti: Offers a tensile strength of ≥520 MPa (75,420 psi) and yield strength of ≥205 MPa (29,740 psi). Its titanium-stabilized composition prevents chromium carbide precipitation during welding or high-temperature exposure, maintaining structural integrity even at 800°C.
   • 316L: Excels in chloride-rich environments (e.g., marine applications) with tensile strength up to 550 MPa (79,770 psi).

2. Bend Strength

   • 06Cr18Ni11Ti demonstrates exceptional ductility (≥40% elongation), enabling severe bending and cold working without cracking. Its austenitic structure allows for complex shapes in automotive exhaust systems and aerospace components.
   • Ferritic grades (e.g., 430) require annealing for deep bending but offer moderate corrosion resistance at lower costs.

3. Corrosion Resistance

   • Chromium (17–19%) and nickel (9–12%) form a self-repairing chromium oxide layer, resisting oxidation, pitting, and crevice corrosion. Titanium additives further inhibit intergranular corrosion in welded joints.

Identification & Marking

Stainless steel grades follow international standards:

• ASTM: 06Cr18Ni11Ti corresponds to UNS S32100.
• JIS: SUS321.
• EN: 1.4541.
  Laser etching ensures traceability for compliance with ASTM, JIS, and EN certifications.

Weight Calculation

Use the formula:
$\text{Weight (kg)}=\text{Thickness (mm)}\times \text{Width (m)}\times \text{Length (m)}\times \text{Density (7.93 g/cm³)}$
Example: A 3 mm thick 06Cr18Ni11Ti plate (1.2m × 2.4m) weighs $3\times 1.2\times 2.4\times 7.93=68.6\text{kg}$.

Why Stainless Steel Rusts?

Despite its name, stainless steel corrodes under specific conditions:

1. Chloride Exposure: Chlorine ions (in seawater or cleaning agents) penetrate the chromium oxide layer, causing pitting corrosion.
2. Mechanical Damage: Scratches or abrasions expose the iron matrix to oxygen, initiating rust formation.
3. Low Oxygen Environments: In stagnant water or enclosed spaces, the oxide film cannot regenerate, leading to localized corrosion.
4. High-Temperature Oxidation: Prolonged exposure above 870°C degrades the protective layer, accelerating oxidation.

Applications

• Avanchy Stainless Steel Suction Plate: Ideal for food-grade applications with hygienic 2B/BA finishes and compliance with FDA standards.
• BBQ Plate Stainless Steel: Withstands high-heat grilling (up to 800°C) and resists grease-induced corrosion, perfect for commercial kitchens.
• Bending Stainless Steel Plate: Used in automotive exhausts, architectural façades, and HVAC systems due to its cold-forming adaptability.

Why Choose Our Stainless Steel Plates?

1. Premium Quality: ISO 9001-certified production using raw materials from TISCO and Baowu Mills.
2. Customization: Laser cutting, perforation, and embossing tailored to industrial needs (e.g., bending stainless steel plate for curved structures).
3. Global Compliance: Meets ASTM, EN, JIS, and GB standards for seamless integration into global supply chains.
4. Logistics Efficiency: 10,000+ ton inventory with air/sea shipping options for wholesale stainless steel plates.
5. Technical Support: 24/7 engineering assistance for material selection and fabrication challenges.
