Multi-Purpose galvanized pipe fittings | Plumbing to Agriculture Use

Product Detail Page: Multi-Purpose Galvanized Pipe Fittings | Plumbing to Agriculture Use

Specifications & Technical Data

Mechanical Properties

Tensile Strength
Our galvanized pipes deliver 315–630 MPa tensile strength, ensuring structural integrity under heavy loads. For instance:

• Q195: 315–430 MPa (Ideal for low-pressure plumbing and irrigation systems)
• Q345: 470–630 MPa (Suitable for agricultural machinery frames and industrial scaffolding)
  The zinc coating enhances resistance to environmental stress, making these pipes 2–3x more durable than uncoated alternatives.

Bend Strength
With a yield strength of 195–345 MPa, these pipes resist deformation under bending forces. The galvanized layer further mitigates fatigue from vibrations, critical for applications like solar panel mounting frames and livestock fencing.

Identification & Marking

1. Laser Etching/Stamping: Permanent markings include grade (e.g., Q235), thickness, and certification codes (e.g., ISO 9001).
2. Color Coding: Compliant with ISO 3864 (e.g., blue for potable water, yellow for gas lines).
3. Batch Traceability: QR codes or alphanumeric codes for quality tracking and compliance reports.

Weight Calculation

Use the formula:
$\text{Weight (kg/m)}=(OD-WT)\times WT\times 0.02466$
Where:

• OD: Outer Diameter (mm)
• WT: Wall Thickness (mm)

Example: A 50 mm OD pipe with 2.5 mm wall thickness:
$(50-2.5)\times 2.5\times 0.02466=2.93\text{kg/m}$
Custom galvanized pipe measurements tools and charts are provided for bulk order planning.

Why Stainless Steel Rusts?

While stainless steel is corrosion-resistant, rust can occur due to:

1. Chloride Exposure: Coastal or agricultural environments degrade the chromium oxide layer.
2. Mechanical Damage: Scratches from improper handling or galvanized pipe strap installation expose the base metal.
3. Galvanic Corrosion: Direct contact with dissimilar metals (e.g., copper fittings) accelerates oxidation.
4. Low-Quality Alloys: Grades like 201/202 lack sufficient nickel, reducing corrosion resistance.

Applications & Maintenance Tips

• Agricultural Use: Corrosion-resistant pipes for irrigation, greenhouse structures, and livestock fencing.
• Plumbing Systems: Compatible with galvanized pipe size chart standards for water and gas distribution.
• Industrial Frameworks: High-strength fittings for machinery, solar panel mounts, and conveyor systems.
• Maintenance: Use epoxy putty for minor leaks; avoid abrasive tools when cutting galvanized pipe to preserve the zinc layer.

Why Choose Our Stainless Steel Products?

1. Superior Corrosion Resistance: 304/316 grades with electro-polished surfaces resist chloride and acid exposure.
2. Customization Expertise: Tailored dimensions, laser-engraved logos, and eco-friendly packaging options.
3. Certified Durability: ISO 9001, SGS, and CE certifications with third-party quality audits.
4. Sustainable Manufacturing: Recyclable materials and low-carbon production processes.
5. Global Logistics: Fast shipping from China’s major ports (Tianjin, Qingdao) with flexible MOQs.
