Multi-Purpose Stainless Steel Metal Plate | 06Cr18Ni11Ti & JIS Standards
Multi-Purpose Stainless Steel Metal Plate | 06Cr18Ni11Ti & JIS Standards
Couldn't load pickup availability
Multi-Purpose Stainless Steel Metal Plate | 06Cr18Ni11Ti & JIS Standards
Product Overview
Our 06Cr18Ni11Ti stainless steel plates (UNS S32100) are titanium-stabilized austenitic stainless steel designed for high-temperature and corrosive environments. Compliant with JIS G4304 and GB/T 20878-2007 standards, these plates combine exceptional corrosion resistance, heat stability, and mechanical strength. Ideal for license plate frames stainless steel, industrial equipment, and architectural cladding, they are available in customizable dimensions and finishes.
Technical Specifications
1. Chemical Composition
| Element | Content (%) |
|---|---|
| Carbon (C) | ≤0.08 |
| Chromium (Cr) | 17.00–19.00 |
| Nickel (Ni) | 9.00–12.00 |
| Titanium (Ti) | ≥5×C%–0.70 |
| Manganese (Mn) | ≤2.00 |
| Silicon (Si) | ≤1.00 |
| Phosphorus (P) | ≤0.045 |
| Sulfur (S) | ≤0.030 |
Certified to JIS G4304, ASTM A240, and EN 1.4541 standards.
2. Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥520 MPa |
| Yield Strength (0.2% Offset) | ≥205 MPa |
| Elongation (%) | ≥40 |
| Hardness (Brinell) | ≤187 HB |
| Density | 7.93 g/cm³ |
3. Physical Properties
| Property | Value |
|---|---|
| Melting Point | 1398–1427°C |
| Thermal Conductivity | 16.3 W/m·K |
| Electrical Resistivity | 0.72 Ω·mm²/m |
| Coefficient of Thermal Expansion | 16.6 × 10⁻⁶/K (0–100°C) |
4. Available Dimensions & Surface Finishes
| Thickness (mm) | Width (mm) | Length (mm) | Surface Finish |
|---|---|---|---|
| 0.5–150 | 1000–2500 | 2000–6000 | 2B, BA, HL, Mirror, No.4 |
| Custom | 100–3000 | Custom | Embossed, Stainless Steel Plate Near Me Textures |
Edge treatments (slit, mill) and laser/plasma cutting available.
Key Features & Applications
1. Titanium Stabilization
The addition of titanium (Ti) minimizes carbide precipitation during welding, enhancing resistance to intergranular corrosion and making it ideal for high-temperature applications like exhaust systems and heat exchangers.
2. Corrosion Resistance
06Cr18Ni11Ti resists oxidation, pitting, and chloride-induced stress corrosion cracking, suitable for marine environments, chemical processing, and license plate frames stainless steel exposed to road salts.
3. High-Temperature Performance
Stable up to 870°C, this grade is perfect for boilers, turbines, and aerospace components requiring thermal durability.
4. Formability & Weldability
- Cold/Hot Working: Easily shaped into complex geometries for automotive parts or architectural panels.
- Welding Compatibility: Compatible with TIG, MIG, and resistance welding without post-weld heat treatment.
Performance Details
1. Tensile & Bend Strength
- Tensile Strength: ≥520 MPa ensures structural integrity under heavy loads, critical for industrial platforms and machinery.
- Bend Strength: Achieves 180° bends at 1T radius without cracking, ideal for custom stainless steel plate near me fabrications.
2. Weight Calculation
Calculate plate weight using:
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.93)
Example: A 10mm × 1.5m × 3m plate ≈ 357.8 kg.
3. Marking & Traceability
Plates are laser-etched with grade (06Cr18Ni11Ti/S32100), thickness, heat number, and certification (JIS G4304 or ASTM A480).
4. Why Stainless Steel Rusts?
Despite its corrosion resistance, rust can occur due to:
- Chloride Exposure: Prolonged contact with seawater or de-icing salts damages the chromium oxide layer.
- Mechanical Damage: Scratches from tools or abrasives expose the iron substrate to oxidation.
- Low Oxygen Environments: Stagnant water or sludge inhibits oxide layer regeneration.
- Chemical Contamination: Acids or alkalis (e.g., bleach) accelerate localized corrosion.
Why Choose Our 06Cr18Ni11Ti Stainless Steel Plates?
- Certified Quality: ISO 9001, ISO 14001, and ISO 45001 certified production with full Mill Test Reports (MTC).
- Custom Solutions: Tailored dimensions (including stainless steel plate near me textures) and precision cutting for license plate frames stainless steel or industrial components.
- Global Compliance: Meets JIS, ASTM, EN, and GB standards for international projects.
- Cost Efficiency: Superior longevity compared to stainless steel vs zinc plated alternatives, reducing lifecycle costs.
- Fast Delivery: 7–15 days lead time for standard orders, with slitting, bending, and polishing services.
