Premium Stainless Steel Exhaust Pipe | 316 Seamless Durability
Premium Stainless Steel Exhaust Pipe | 316 Seamless Durability
Regular price
$1,760.00 SGD
Regular price
Sale price
$1,760.00 SGD
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Product Detail Page: Premium Stainless Steel Exhaust Pipe** | 316 Seamless Durability
Technical Specifications
Engineered for extreme durability and compliance with ASTM A312/A358 standards.
| Parameter | ASTM 316 Seamless Specifications |
|---|---|
| Material Grade | 316/316L (UNS S31600/S31603) |
| Outer Diameter (OD) | Stainless steel pipe diameters: 6–2600 mm (±1% tolerance) |
| Wall Thickness | 0.6–50 mm (SCH 5S to XXS) |
| Surface Finish | 2B (cold-rolled), BA (bright annealed), or hairline polish |
| Hardness (Rockwell B) | 85 HRB (max) |
| Tensile Strength | 515–700 MPa |
| Yield Strength | 205 MPa (min) |
| Elongation | 35–40% |
| Temperature Range | -20°C to 900°C |
| Certifications | ASTM A312, ASME SA358, EN 10204-3.1 |
Key Features
Mechanical & Chemical Properties
- Superior Corrosion Resistance: The stainless steel exhaust pipe contains 16–18% chromium and 2–3% molybdenum, offering exceptional resistance to pitting and crevice corrosion in chloride-rich environments like marine or automotive exhaust systems.
- High-Temperature Stability: Retains tensile strength (>500 MPa) and structural integrity at temperatures up to 900°C, ideal for turbochargers and industrial furnaces.
- Seamless Construction: Cold-drawn or hot-extruded seamless pipes eliminate weld seams, reducing weak points and ensuring uniform stress distribution under vibration or pressure.
Weight Calculation Formula
Calculate pipe weight using:
Example: For a stainless steel pipe diameter of 100mm with 5mm wall thickness:
Bending Strength & Fatigue Resistance
- Bend Strength: Seamless 316 pipes withstand 180° bending without cracking, critical for custom stainless steel muffler pipe configurations.
- Cyclic Load Resistance: Fatigue strength of 240 MPa at 10⁷ cycles ensures longevity in high-vibration automotive or aerospace applications.
Manufacturing Process
Precision engineering for unmatched reliability.
| Stage | Description |
|---|---|
| Material Selection | 316/316L billets sourced from ISO 9001-certified mills with traceable PMI reports. |
| Forming | Cold drawing (for thin walls) or hot extrusion (for thick walls) to ensure seamless integrity. |
| Heat Treatment | Solution annealing at 1050°C followed by rapid quenching to optimize corrosion resistance. |
| Surface Treatment | Pickling, electropolishing, or passivation to achieve Ra ≤0.8μm for reduced friction and bacterial growth. |
| Quality Assurance | Hydrostatic testing (1.5x max pressure), eddy current inspection, and third-party lab certification. |
Why Stainless Steel Rusts & Prevention
While stainless steel exhaust pipes are inherently corrosion-resistant, improper handling or environmental factors can cause localized rusting:
- Chloride Exposure: Prolonged contact with road salt or seawater degrades the chromium oxide layer. Use stainless steel pipe clamps with insulating sleeves to prevent galvanic corrosion.
- Mechanical Damage: Scratches from improper tooling expose the base metal. Post-installation passivation restores the protective layer.
- Thermal Stress: Repeated heating/cooling cycles above 900°C may cause carbide precipitation. 316L (low-carbon variant) is recommended for welded assemblies.
Identification & Marking
- Laser Etching: Permanent markings include grade (316/316L), ASTM standard, heat number, and stainless steel pipe diameters.
- Color Coding: Red bands for high-temperature variants (316) and blue for low-carbon (316L) pipes.
Why Choose Our Stainless Steel Products?
- Certified Quality: All stainless steel exhaust pipes comply with ASTM, ASME, and EN 10204-3.1 standards, backed by mill test reports.
- Custom Solutions: Tailor stainless steel pipe diameters, wall thicknesses, and surface finishes for automotive, marine, or industrial exhaust systems.
- Global Supply Network: Partnered with mills like Baosteel and Tisco, ensuring rapid delivery to 50+ countries.
- Eco-Friendly: 100% recyclable material with low VOC emissions during production, aligning with ISO 14001 environmental standards.
