Product Specifications

Key Properties

1. Tensile & Yield Strength

   • 316L: Offers tensile strength of 485–620 MPa (70,340–89,923 psi) and yield strength ≥205 MPa (29,740 psi). The addition of molybdenum (2–3%) enhances resistance to chloride-induced pitting, making it ideal for marine or chemical environments.
   • 304L: Provides tensile strength of 515–690 MPa (74,694–100,076 psi) with lower carbon content (≤0.03%), reducing intergranular corrosion risks during welding.

2. Bend Strength & Ductility

   • Both grades exhibit ≥40% elongation, enabling deep drawing and severe bending without cracking. 316L is preferred for complex shapes in architectural cladding, while 304L excels in food-grade applications due to its hygienic 2B finish.

3. Corrosion Resistance

   • Chromium (16–18% in 316L; 18–20% in 304L) forms a self-healing oxide layer. 316L outperforms in chloride-rich settings, while 304L resists organic acids in food processing.

Identification & Marking

• International Standards:
  • 316L: ASTM A240, EN 1.4404, JIS SUS316L.
  • 304L: ASTM A240, EN 1.4307, JIS SUS304L.
• Laser-etched codes include heat batch numbers, mill certifications (TISCO, Baosteel), and compliance with ISO 9001.

Weight Calculation

Use the formula:
$\text{Weight (kg)}=\text{Thickness (mm)}\times \text{Width (m)}\times \text{Length (m)}\times \text{Density (7.93 g/cm³)}$
Example: A 5 mm thick 316L plate (1.2m × 2.4m) weighs:
$5\times 1.2\times 2.4\times 7.93=114.5\text{kg}$.

Why Stainless Steel Rusts?

While stainless steel is corrosion-resistant, degradation occurs under specific conditions:

1. Chloride Exposure: Saltwater or de-icing agents penetrate the oxide layer, causing localized pitting.
2. Mechanical Damage: Scratches expose the iron matrix to oxygen, initiating rust.
3. Low Oxygen Environments: Stagnant water inhibits oxide regeneration, leading to crevice corrosion.
4. High-Temperature Oxidation: Prolonged exposure above 870°C degrades protective films.

Applications

• Custom Stainless Steel Plates: Tailored for architectural façades, industrial machinery, and stainless steel charger plates with No.4/HL finishes for aesthetic durability.
• Gold Plated Stainless Steel: Decorative items like jewelry or luxury tableware typically last 2–5 years with proper care, as gold layers (0.5–5µm) wear off under friction or chemical exposure.

Why Choose Our Stainless Steel Plates?

1. Dual-Certified Quality: ISO 9001-certified production with raw materials from TISCO and Baosteel, ensuring compliance with ASTM/EN/JIS standards.
2. Precision Customization: Laser cutting and perforation for custom stainless steel plates, including perforated sheets for filtration or decorative panels.
3. Global Logistics: 10,000+ ton inventory with air/sea shipping (MOQ: 1 ton) and 7–15-day delivery.
4. Sustainability: 90% recycled content and full recyclability, aligning with eco-friendly practices.
5. Technical Support: 24/7 engineering assistance for material selection, fabrication, and corrosion prevention.
