Reliable Stainless Steel Metal Plate | 06Cr19Ni10 & EN Standards
Reliable Stainless Steel Metal Plate | 06Cr19Ni10 & EN Standards
Couldn't load pickup availability
Reliable Stainless Steel Metal Plate | 06Cr19Ni10 & EN Standards
Product Specifications
| Property | 06Cr19Ni10 (304) | EN Standards (1.4301) |
|---|---|---|
| Thickness | 0.1–180 mm | 0.4–6 mm |
| Width | 300–2500 mm | 1000–2400 mm |
| Length | Custom up to 6000 mm | 2000–6000 mm |
| Surface Finish | 2B, HL, No.4, Mirror | Pickling, Mill, 8K |
| Hardness (HV) | 187 HBW (max) | ≤187 HBW |
| Density | 7.93 g/cm³ | 7.85–7.93 g/cm³ |
| Operating Temp | -196°C to 800°C | -50°C to 300°C |
Mechanical Properties
Tensile Strength
06Cr19Ni10 stainless steel exhibits a minimum tensile strength of 520 MPa and a yield strength of ≥210 MPa. This ensures excellent structural integrity under high-stress conditions, making it suitable for industrial machinery, construction, and food processing equipment.
Bending Strength
The material’s ductility (≥35% elongation in annealed state) allows for easy cold forming and bending without cracking. Its austenitic structure provides superior resistance to deformation under load, even in repetitive stress environments.
Identification & Marking
- Standard Markings:
- ASTM: S30400
- DIN: 1.4301
- GB/T: 06Cr19Ni10
- Surface Marking: Laser-etched or stamped with grade, thickness, and batch number for traceability.
Weight Calculation
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.93 g/cm³)
Example: A 2mm × 1m × 2m plate weighs 31.72 kg (2×1×2×7.93).
Why Stainless Steel Corrodes?
Despite its corrosion resistance, 06Cr19Ni10 may rust under specific conditions:
- Chloride Exposure: Chlorides (e.g., seawater, salts) penetrate the passive chromium oxide layer, causing pitting.
- Improper Heat Treatment: Lack of solid solution treatment reduces chromium distribution, weakening corrosion resistance.
- Intergranular Corrosion: Sensitization at 500–800°C forms chromium-depleted zones, accelerating oxidation.
- Mechanical Damage: Scratches or abrasions expose the base metal to oxidation.
Key Features & Applications
Material Advantages
- Corrosion Resistance: Chromium (18–20%) and nickel (8–11%) form a protective oxide layer.
- Hygienic: Ideal for food processing, medical devices, and pharmaceuticals due to non-porous surfaces.
- Aesthetic Versatility: Available in yellow ion-plated stainless steel for decorative applications.
Processing Techniques
| Process | Description |
|---|---|
| Cold Rolling | Enhances surface smoothness and precision. |
| Polishing | Achieves mirror or hairline finishes. |
| Etching | Creates custom patterns for architectural use. |
Comparative Insights
- zinc plated screws vs stainless steel: While zinc plating offers temporary rust prevention, stainless steel (e.g., 06Cr19Ni10) provides lifelong corrosion resistance without coating degradation.
- will stainless steel gold plated tarnish: Gold-plated layers may wear over time, but the base stainless steel remains intact, ensuring durability.
Why Choose Our Stainless Steel Plates?
- Certified Quality: Compliant with ASTM A240, EN 10088, and ISO 9001.
- Custom Solutions: Tailored dimensions, surface finishes, and embossing for diverse industries.
- Global Reliability: Exported to 20+ countries with BV/SGS certifications.
- Sustainable: 100% recyclable with eco-friendly production processes.
- Technical Support: Expert guidance on material selection and corrosion prevention.
