Robust Stainless Steel Metal Plate | 06Cr18Ni11Ti & High Tensile

Robust Stainless Steel Metal Plate | 06Cr18Ni11Ti & High Tensile

$1,650.00 SGD
$1,650.00 SGD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity

Robust Stainless Steel Metal Plate | 06Cr18Ni11Ti & High Tensile

Technical Specifications

Parameter Details
Material Grade 06Cr18Ni11Ti (Equivalent to ASTM 321 / EN 1.4541)
Thickness Range 0.5 mm – 25 mm (Customizable for stainless steel plates plasma cutting Italy)
Hardness (Surface) HRB 70–90 (Annealed); HRC ≤20 (Cold-Worked)
Dimensions Width: 1000–4500 mm; Length: Custom-cut up to 12,000 mm
Tensile Strength ≥520 MPa
Yield Strength ≥205 MPa
Elongation ≥40%
Surface Finish 2B (Matte), BA (Bright Annealed), HL (High-Gloss Polish)
Weight Formula Weight (kg) = Thickness (mm) × Area (m²) × 7.93 (Density in g/cm³)
Thermal Conductivity 16.3 W/m·K (100°C)
Melting Point 1398–1454°C

Performance Attributes

1. Tensile & Bend Strength

The 06Cr18Ni11Ti grade delivers exceptional tensile strength (≥520 MPa) and bend resistance (≈1.5× tensile strength) due to its titanium-stabilized austenitic microstructure. This combination ensures structural integrity under high-stress conditions, making it ideal for heavy-duty applications like industrial machinery, architectural frameworks, and stainless steel plates bowls or stainless steel plates cups in food processing. The material retains over 85% of its strength at temperatures up to 800°C, preventing deformation in high-heat environments.



2. Identification & Certification

  • ASTM Standards: Laser-etched UNS S32100 identifiers ensure traceability.
  • EN 1.4541 Compliance: Meets EU standards for chemical composition and mechanical properties.
  • Surface Marking: Includes mill codes, heat numbers, and compliance notes for stainless steel plates plasma cutting Italy applications.

3. Weight Calculation

Use the formula:

For example, a stainless steel plates bowls component with 2 mm thickness and 0.5 m² area weighs 7.93 kg.

4. Causes of Stainless Steel Rust

Despite its corrosion resistance, localized rust may occur due to:

  • Chloride Exposure: Coastal environments or industrial chemicals degrade the passive chromium oxide layer.
  • Mechanical Damage: Scratches or improper welding expose the base metal to oxidation.
  • Thermal Stress: Rapid temperature changes (e.g., in stainless steel plates plasma cutting Italy) induce micro-cracks, accelerating corrosion.

Material Advantages

Enhanced Durability

  • Titanium Stabilization: Titanium (5×(C%-0.02)~0.8%) prevents carbide precipitation, enhancing resistance to intergranular corrosion.
  • High-Temperature Stability: Retains mechanical properties up to 900°C, ideal for exhaust systems and industrial ovens.

Precision Manufacturing

  • Plasma Cutting: CNC plasma cutting (±0.1 mm tolerance) ensures precision for stainless steel plates plasma cutting Italy projects.
  • Hygienic Finishes: BA or HL polishing (≤Ra 0.1 μm) meets food-grade standards for stainless steel plates bowls and cups.

Sustainability

  • 100% Recyclable: Reduces lifecycle costs and environmental impact.

Why Choose Our 06Cr18Ni11Ti Stainless Steel?

  1. Certified Material Excellence

    • Dual-certified (ASTM 321 & EN 1.4541) with mill test reports for full traceability.
    • Nitrogen-enriched variants available for enhanced pitting resistance.

  2. Customization & Versatility

    • Tailored dimensions for curved architectural elements or stainless steel plates cups production.
    • Multiple finishes (matte, mirror, brushed) to suit aesthetic and functional needs.

  3. Technical Expertise

    • Free consultation on welding protocols, corrosion prevention, and load calculations.

  4. Global Compliance & Warranty

    • 10-year warranty against material defects and premature corrosion.
