Rugged Stainless Steel 90 Degree Elbow | ANSI B16.9 Compliant
Rugged Stainless Steel 90 Degree Elbow | ANSI B16.9 Compliant
Couldn't load pickup availability
Product Detail Page: Rugged Stainless Steel 90 Degree Elbow | ANSI B16.9 Compliant
Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | SS-90E-B16.9 |
| Material | Stainless Steel 304/316L, 316Ti, 321 (ASTM A403) |
| Standard | ANSI B16.9, ASME B16.25, MSS SP-75, DIN 2605 |
| Angle | 90° (Long Radius: 1.5D; Short Radius: 1D) |
| Size Range | 1/2" to 48" (DN15 to DN1200) |
| Wall Thickness | SCH10, SCH40, SCH80, XS, XXS (1.5mm to 40mm) |
| Pressure Rating | 2000 PSI (138 bar) at 20°C |
| Hardness | HRB 70–90 (Rockwell B Scale) |
| Surface Finish | Electro-polished, Sandblasted, or Mirror Finish (Ra ≤0.8μm) |
| Connection Type | Butt-Welded, Threaded, or Stainless Steel Flanged Elbow (ASME B16.5) |
| Temperature Range | -196°C to 800°C |
| Certifications | ISO 9001, PED 2014/68/EU, NACE MR0175 |
Mechanical Properties
Tensile Strength
The stainless steel elbows exhibit exceptional tensile strength (≥515 MPa for Grade 304; ≥620 MPa for Grade 316), ensuring resistance to deformation under high-pressure conditions. This property is critical for industrial applications such as oil and gas pipelines, where mechanical stress is frequent.
Bend Strength
Designed to withstand cyclic loading, these elbows maintain structural integrity even under repeated stress. The bend strength (≥205 MPa for 304) is enhanced by seamless manufacturing techniques, reducing weak points.
Identification & Marking
Each elbow is laser-etched or stamped with the following:
- Material Grade (e.g., 304, 316L)
- Size (NPS and DN)
- Wall Thickness (SCH)
- Standard Compliance (ANSI B16.9)
- Manufacturer’s Logo
This traceability ensures compliance with global quality standards.
Weight Calculation Formula
Weight (kg) = / 1000
Example: For a 6" SCH40 elbow (OD = 168.3mm, WT = 7.11mm):
Weight ≈ 2.45 kg. Custom weights for stainless steel flanged elbows are calculated based on flange dimensions.
Why Stainless Steel Elbows Resist Rust?
While stainless steel is inherently corrosion-resistant, improper handling or environmental factors can cause localized rusting:
- Chrome Depletion: Insufficient chromium content (<10.5%) weakens the passive oxide layer.
- Chloride Exposure: Coastal or chemical environments accelerate pitting corrosion in 304 grades; 316/L is preferred for such conditions.
- Mechanical Damage: Scratches or weld spatter disrupt the surface, exposing raw steel to oxidation.
- Intergranular Corrosion: Poor welding practices (e.g., lack of argon shielding) cause carbide precipitation in heat-affected zones.
Key Advantages
- Durability: Withstands extreme temperatures and pressures, ideal for nuclear plants and petrochemical systems.
- Hygienic Design: Electro-polished surfaces prevent bacterial growth, compliant with FDA and 3A sanitary standards.
- Customization: Available in stainless steel flanged elbow, threaded, or grooved designs to match system requirements.
Why Choose Us?
As leading stainless steel elbows suppliers, we offer:
✅ Global Certifications: ISO 9001, PED, and ABS-approved manufacturing.
✅ Inventory Flexibility: Over 10,000 SKUs in stock, ready for urgent orders.
✅ Local Accessibility: Find stainless steel elbows near me via our warehouses in the US, EU, and Asia.
✅ Technical Support: 24/7 engineering assistance for custom designs and material selection.
✅ Sustainable Practices: 100% recyclable materials and eco-friendly production.
