Rust-Proof Stainless Steel H Beam | Bulk Orders, 3-Day Dispatch
Product Specifications
Structural and technical details for stainless steel H beam applications.
| Property | 316 Stainless Steel H Beam | Carbon Steel H Beam | Advanced Stainless Steel H Beam |
|---|---|---|---|
| Standard Sizes (H×W×T) | 100×100×6mm – 500×200×12mm | 150×150×10mm – 600×300×15mm | Customizable up to 800×300×20mm |
| Hardness (Rockwell) | B85-B95 | B75-B90 | B90-B100 |
| Tensile Strength | 520-860 MPa | 370-550 MPa | 860-1,200 MPa |
| Yield Strength | 210-450 MPa | 235-345 MPa | 450-950 MPa |
| Surface Finish | Bead-blasted, passivated | Hot-rolled, galvanized | Laser-polished, electropolished |
| Corrosion Resistance | Excellent (Cr/Ni/Mo alloy) | Moderate (Zn coating) | Superior (Advanced austenitic) |
| Length Options | 6m, 12m (custom up to 20m) | 6m, 12m | 6m, 12m, 20m (precision-cut) |
| Weight (kg/m) | 16.9 – 88.1 | 23.6 – 109.3 | 25.1 – 120.5 |
Technical Highlights
Tensile & Bend Strength
Stainless steel H beams excel in high-stress environments due to their optimized stainless steel H beam dimensions. The tensile strength of advanced stainless steel H beam (up to 1,200 MPa) outperforms traditional carbon steel (370-550 MPa) by 225%, ensuring structural integrity in seismic zones and heavy-load applications. Bend strength is enhanced by the H-shaped profile, which distributes stress evenly across the web and flanges, minimizing deformation.
Identification & Marking
Each wholesale stainless steel H beam is laser-etched with grade identifiers (e.g., 316, 304) and stainless steel H beam dimensions (height, width, thickness). Carbon steel beams use stamped codes (e.g., Q235), while advanced stainless steel H beam includes QR codes for traceability and compliance with ASTM A276/ASME SA479 standards.
Weight Calculation
For stainless steel H beam, weight is calculated using:
Example: A 300×150×10mm beam weighs ~36.7 kg/m. Custom lengths reduce material waste, with bulk orders offering ±0.5mm tolerance.
Corrosion Resistance & Rust Prevention
Though stainless steel H beam contains 16-18% chromium and 10-12% nickel, localized rust may occur in chloride-rich environments (e.g., coastal areas). Key safeguards include:
- Passivation: A chromium oxide layer blocks oxygen diffusion, preventing oxidation.
- Molybdenum Enhancement: 316-grade beams include 2-3% molybdenum for superior resistance to pitting and crevice corrosion.
- Surface Treatments: Bead-blasting removes micro-crevices, while electropolishing enhances smoothness for harsh industrial settings.
Why Choose Our Stainless Steel H Beams?
Positioned at the bottom for emphasis, as requested.
-
Unmatched Durability
- Advanced stainless steel H beam withstands temperatures up to 870°C (1,600°F) and cyclic loads without cracking.
- 100% recyclable, meeting ISO 14001 environmental standards.
-
Bulk Order Advantages
- Wholesale stainless steel H beam discounts for orders >50 tons, with 3-day dispatch via air/sea freight.
- Custom packaging (bundled or containerized) to prevent transit damage.
-
Precision Engineering
- CNC-cut stainless steel H beam dimensions ensure seamless assembly in skyscrapers, bridges, and offshore platforms.
- Mill test certificates (MTC) and EN 10204 3.1 compliance.
-
Global Compliance
- Meets ASTM, JIS, DIN, and GB/T 11263-2010 standards for global projects.
-
24/7 Technical Support.
- Expert guidance on load calculations, corrosion prevention, and weldability.
