Stainless Steel Flat Bar | Cost-Effective ASTM-Certified
Stainless Steel Flat Bar | Cost-Effective ASTM-Certified
Couldn't load pickup availability
Product Detail Page: Stainless Steel Flat Bar | Cost-Effective ASTM-Certified
Technical Specifications & Properties
(Structured Tables for SEO Optimization)
1. Dimensional Specifications
| Parameter | Range | Standards |
|---|---|---|
| Thickness | 3mm – 30mm (Hot Rolled) / 0.3mm – 6mm (Cold Drawn) | ASTM A276, A484, EN 10088-3 |
| Width | 10mm – 500mm | ASME SA479, DIN 1017 |
| Length | 2m – 6m (Standard) / Custom Cut Lengths | ISO 9445, JIS G4303 |
| Surface Finish | Pickled, Bright, Polished, Brushed | ASTM A480, EN 10088-2 |
Key Products:
- Stainless steel flat bar: Ideal for flat top grill stainless steel and stainless steel flat top stove components due to heat resistance and structural integrity.
- Grades Available: 304, 304L, 316L, 430, 410 (compliant with ASTM/EN standards).
2. Material Properties
| Grade | Hardness (HV) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|---|
| 304 | 170 – 200 | 515 – 720 | ≥205 | ≥40 |
| 316L | 180 – 220 | 520 – 670 | ≥215 | ≥40 |
| 430 | 150 – 180 | 450 – 600 | ≥250 | ≥22 |
Source: ASTM A276, EN 10088-3.
3. Manufacturing Processes
| Process | Applications | Advantages |
|---|---|---|
| Hot Rolling | Structural frameworks, industrial machinery | High strength; cost-effective for bulk orders |
| Cold Drawing | Precision tools, medical equipment, decorative trim | Smooth surface; tight dimensional tolerances |
| Annealing | Enhanced ductility for bending/welding | Reduces internal stress; improves corrosion resistance |
| Polishing | Stainless steel flat top stove surfaces, architectural accents | Aesthetic finish; hygienic & easy to clean |
Certifications: ISO 9001, PED, CE, and RoHS.
Detailed Technical Descriptions
1. Tensile & Bend Strength
Stainless steel flat bar exhibits exceptional tensile strength (up to 720 MPa for Grade 304), making it suitable for load-bearing applications like flat top grill stainless steel frames. Its bend strength is enhanced through controlled annealing, ensuring structural integrity under cyclic thermal stress (e.g., repeated heating/cooling in stoves).
2. Weight Calculation
Use the formula to estimate flat bar weight:
Weight (kg/m) = Thickness (mm) × Width (mm) × 0.00785
Example: A 10mm × 50mm stainless steel flat bar weighs ≈3.925 kg/m.
3. Identification Marking
All products are laser-etched with:
- Grade (e.g., 304, 316L)
- Batch Number (for traceability)
- ASTM/EN Standard (e.g., ASTM A276, EN 10088-3)
This ensures compliance with global quality benchmarks.
4. Causes of Stainless Steel Corrosion
Despite high durability, corrosion may occur due to:
- Chloride Exposure: Coastal environments or de-icing salts degrade protective chromium oxide layers.
- Galvanic Corrosion: Contact with dissimilar metals (e.g., carbon steel) in humid conditions.
- Thermal Stress: Excessive temperatures (>400°C for 304 grade) may weaken oxidation resistance.
Applications & Custom Solutions
- Flat top grill stainless steel: Grade 430 bars are cost-effective for heat-resistant grill surfaces.
- Stainless steel flat top stove: Polished 316L bars resist acidic food residues and high-temperature warping.
- Architectural cladding: Brushed or mirror-finished bars for modern façades and handrails.
Why Choose Our Stainless Steel Flat Bars?
(Positioned at the Bottom for SEO Prioritization of Technical Content)
- ASTM-Certified Quality: Raw materials sourced from ISO 9001-certified mills (e.g., Tsingshan Group).
- Customization: No MOQ for stainless steel flat bar; tailored dimensions, grades, and finishes.
- Cost Efficiency: Bulk pricing 15% lower than EU/US suppliers; 72-hour dispatch for urgent orders.
- Sustainability: 70% recycled content; compliant with RoHS and REACH regulations.
- Technical Support: 24/7 engineering consultation for material selection and corrosion prevention.
