Product Overview

Our ASTM-certified 304L/316L stainless steel pipes are engineered for superior performance in corrosive, high-temperature, and high-pressure environments. Designed for applications ranging from chemical processing to stainless steel welded pipe systems, these pipes combine exceptional durability, hygienic design, and compliance with international standards. With global stock availability and fast delivery, we ensure seamless integration into projects demanding reliability and precision.

Technical Specifications

For precise pipe stainless steel dimension requirements, consult our stainless steel pipe schedule chart or contact our technical team.

Key Attributes

1. Corrosion Resistance:
   • 304L: 18-20% chromium and 8-12% nickel resist oxidation and mild acids.
   • 316L: Added 2-3% molybdenum enhances chloride resistance, ideal for marine and chemical environments.
2. Low Carbon Content: ≤0.03% carbon minimizes carbide precipitation during welding, reducing intergranular corrosion risks.
3. Hygienic Design: Mirror-polished surfaces (Ra ≤0.3μm) inhibit bacterial growth, suitable for food and pharmaceutical industries.
4. Thermal Stability: Withstands temperatures up to 870°C (304L) and 843°C (316L), perfect for exhaust and heat exchanger systems.

Detailed Performance Characteristics

Tensile & Bend Strength

• Tensile Strength:
  • Both grades achieve ≥485 MPa, ensuring structural integrity in high-pressure systems like hydraulic lines and stainless steel welded pipe networks.
  • 316L’s molybdenum content provides superior resistance to stress corrosion cracking in chloride-rich environments.
• Bend Strength:
  • The austenitic microstructure offers exceptional ductility, retaining roundness even under tight-radius bends. This property is critical for custom pipe stainless steel dimension layouts in HVAC and industrial plumbing.

Identification Methods

• Laser Etching/Stamping: Permanent markings include grade (e.g., "304L" or "316L"), OD, thickness, and heat number per ASTM A480.
• Certification: Mill Test Reports (MTRs) validate chemical composition (Cr, Ni, Mo) and mechanical properties for full traceability.

Weight Calculation

Use the formula:
Weight (kg/m)=1000(OD−WT)×WT×0.0248
Example: A stainless steel pipe schedule chart entry for a 100mm OD pipe with 5mm wall thickness weighs ~11.6 kg/m.

Causes of Stainless Steel Rust

Despite its corrosion resistance, rust can occur under:

1. Chloride Exposure: Seawater, de-icing salts, or industrial chemicals disrupt the passive chromium oxide layer, causing pitting.
2. Mechanical Damage: Scratches or abrasions expose raw metal to oxidation.
3. Galvanic Corrosion: Contact with dissimilar metals (e.g., carbon steel) in conductive fluids accelerates degradation.
4. Improper Welding: High carbon precipitation in heat-affected zones reduces corrosion resistance, mitigated by using low-carbon 304L/316L.

Applications

• Chemical Processing: Resists sulfuric acid, alkalis, and chlorides.
• Food & Pharma: Complies with NSF/ANSI 372 standards for potable water.
• Exhaust Systems: High-temperature stability for stainless steel welded pipe in automotive and industrial chimneys.

Why Choose Our Stainless Steel Pipes?

1. Certified Quality: Compliant with ASTM, ASME, and ISO standards, backed by third-party inspections.
2. Global Stock: Immediate dispatch of custom pipe stainless steel dimension orders, minimizing downtime.
3. Custom Solutions: Tailored OD, wall thickness, and surface finishes (e.g., electropolished) for seamless integration.
4. Technical Expertise: 20+ years in precision manufacturing for extreme environments.
5. Sustainability: 100% recyclable with a low carbon footprint.
