Stainless Steel Pipe | Precision-Cut 304L/316 Tubing Kits

Product Overview

Our Precision-Cut 304L/316 Stainless Steel Tubing Kits are engineered for applications demanding exact tolerances, corrosion resistance, and durability in high-stress environments. Designed for industries like aerospace, stainless steel hydraulic pipe fittings systems, and chemical processing, these kits combine ASTM/ASME-certified materials with advanced laser/plasma cutting technology for seamless integration into critical infrastructure. Customizable dimensions, surface finishes, and bulk packaging ensure efficiency for both small-scale projects and industrial-scale operations.



Technical Specifications

Property 304L (UNS S30403) 316 (UNS S31600)
Standards ASTM A312, A269, ASME SA213 ASTM A312, A269, ASME SA213
Material Grade Austenitic (Low Carbon) Austenitic (Mo-Enhanced)
Outer Diameter (OD) 6mm – 610mm (1/4" – 24") 6mm – 610mm (1/4" – 24")
Wall Thickness 0.35mm – 60mm 0.5mm – 40mm
Hardness (HRB) ≤90 ≤95
Tensile Strength ≥485 MPa (70,300 psi) ≥485 MPa (70,300 psi)
Yield Strength ≥170 MPa (24,700 psi) ≥170 MPa (24,700 psi)
Surface Finish Annealed, Pickled, Polished Electropolished, Mirror Finish
Processing Laser/Plasma Cut, Cold-Drawn Precision-Cut, ERW-Welded

For custom stainless steel pipe chart references or how to cut stainless steel pipe guidance, consult our technical team.



Key Attributes

  1. Precision Cutting: Laser and plasma cutting ensures ±0.1mm tolerance, ideal for stainless steel hydraulic pipe fittings requiring leak-proof joints.
  2. Corrosion Resistance:
    • 304L: 18-20% chromium resists oxidation and mild acids.
    • 316: 2-3% molybdenum enhances chloride resistance for marine and chemical environments.
  3. Thermal Stability: Withstands temperatures up to 870°C (304L) and 843°C (316), suitable for exhaust and hydraulic systems.
  4. Custom Kits: Pre-cut lengths (1m–12m) with deburred edges reduce installation time by 30%.

Detailed Performance Characteristics

Tensile & Bend Strength

  • Tensile Strength:
    Both grades achieve ≥485 MPa, ensuring structural integrity in high-pressure systems like hydraulic lines and offshore platforms. The austenitic microstructure prevents stress concentration, critical for welded joints in stainless steel hydraulic pipe fittings.
  • Bend Strength:
    Cold-drawn pipes retain ductility under tight-radius bends (1.5x OD). Use mandrel bending tools for how to cut stainless steel pipe applications to avoid work hardening.

Identification Methods

  • Laser Etching/Stamping: Permanent markings include grade ("304L" or "316"), OD, thickness, and heat number per ASTM A480.
  • Certification: Mill Test Reports (MTRs) validate chemical composition (Cr, Ni, Mo) and mechanical properties.

Weight Calculation

Use the formula:

Example: A 100mm OD pipe with 5mm wall thickness weighs ~11.6 kg/m. Download our stainless steel pipe chart for bulk calculations.

Causes of Stainless Steel Rust

Despite its corrosion resistance, rust can occur under:

  1. Chloride Exposure: Seawater or de-icing salts disrupt the passive chromium oxide layer, causing pitting.
  2. Mechanical Damage: Scratches from improper how to cut stainless steel pipe techniques expose raw metal to oxidation.
  3. Galvanic Corrosion: Contact with carbon steel in conductive fluids accelerates degradation.
  4. Improper Welding: High carbon precipitation in heat-affected zones reduces corrosion resistance. Use low-carbon 304L/316L and post-weld annealing.

Applications

  • Hydraulic Systems: Stainless steel hydraulic pipe fittings for high-pressure fluid transfer.
  • Aerospace: Precision-cut tubes for fuel lines and structural components.
  • Chemical Processing: ERW-welded 316 pipes handle sulfuric acid and chlorides.

Why Choose Our Stainless Steel Pipes?

  1. Certified Quality: ASTM/ASME compliance with third-party inspections.
  2. Global Supply: As a leading exporter, we ensure 15-30 day delivery for bulk stainless steel pipe chart orders.
  3. Custom Solutions: Tailored OD, wall thickness, and surface finishes (e.g., electropolished).
  4. Technical Support: 24/7 guidance on how to cut stainless steel pipe and welding best practices.
  5. Sustainability: 100% recyclable with eco-friendly packaging.
