Stainless Steel Pipes | 316Ti/310S Oxidation-Resistant Solutions

Property	316Ti Stainless Steel	310S Stainless Steel
Material Grade	UNS S31635 / EN 1.4571	UNS S31008 / EN 1.4845
Chemical Composition	16–18% Cr, 10–14% Ni, 2–3% Mo, Ti	24–26% Cr, 19–22% Ni, ≤0.08% C
Tensile Strength	520–750 MPa	≥520 MPa
Yield Strength	205 MPa	≥205 MPa
Hardness (Rockwell B)	85–95 HRB	70–90 HRB
Temperature Resistance	Up to 925°C (continuous)	Up to 1150°C (continuous)
Corrosion Resistance	Superior in acidic/chloride environments	Excellent oxidation resistance at high temperatures
Standard Compliance	ASTM A213, A312, EN 1.4571	ASTM A312, A269, EN 1.4845
Dimensions (OD)	3 inch stainless steel pipe: 6–2500 mm	6–2500 mm
Wall Thickness	0.5–150 mm	0.5–150 mm
Surface Finish	Electropolished, Annealed & Pickled	Annealed, Mirror Polished (Ra ≤0.2μm)
Process	Seamless, TIG Welded	Cold Drawn, Seamless
Key Applications	corrugated stainless steel gas pipe, chemical reactors, marine hardware	Boilers, heat exchangers, 316 stainless steel pipe for high-temperature systems

Oxidation & Corrosion Resistance
- 316Ti: Titanium stabilization prevents carbide precipitation during welding, ideal for corrugated stainless steel gas pipe exposed to acidic or chloride-rich environments. Molybdenum (2–3%) enhances pitting resistance in marine and chemical processing plants.
- 310S: High chromium (24–26%) and nickel (19–22%) ensure exceptional oxidation resistance at temperatures up to 1150°C, perfect for boiler tubes and furnace components.
Mechanical Strength
- Tensile Strength: 316Ti achieves 750 MPa, outperforming standard 316L in high-stress applications like offshore platforms. 310S maintains structural integrity at extreme temperatures, with creep strength critical for 3 inch stainless steel pipe in power plants.
- Bend Strength: Both grades support cold bending up to 180° without cracking, essential for retrofitting 316 stainless steel pipe networks in HVAC systems.
Versatility
- Seamless/Welded Options: Custom 3 inch stainless steel pipe dimensions for petrochemical pipelines and architectural frameworks.
- Surface Treatments: Electropolished finishes on corrugated stainless steel gas pipe minimize bacterial adhesion in sanitary applications.

The weight of stainless steel pipes is calculated using:
$Weight (kg/m) = \frac{( O D - W T ) \times W T \times 0.02466}{1000}$
Where:

Example: A 3 inch stainless steel pipe (76.2 mm OD, 5 mm WT) weighs 8.81 kg/m, ideal for structural and fluid transport systems.

Laser Etching: ASTM/EN standards, heat number, and grade (e.g., "316Ti" or "310S") for traceability.
Color Coding: Optional bands for inventory management in industrial projects requiring 316 stainless steel pipe.

Despite their corrosion-resistant properties, rust can occur due to:

Chloride Exposure: Coastal or industrial environments degrade passive oxide layers, especially in welded corrugated stainless steel gas pipe joints without post-weld cleaning.
Intergranular Corrosion: Improper welding of 316Ti without nitrogen stabilization leads to chromium carbide formation at grain boundaries.
Surface Contamination: Iron particles from cutting tools or grease disrupt the protective chromium oxide layer, critical for 316 stainless steel pipe in hygienic industries.
Galvanic Corrosion: Direct contact with dissimilar metals (e.g., copper) accelerates oxidation. Insulating gaskets mitigate this risk in 3 inch stainless steel pipe installations.

316Ti: Chemical reactors, corrugated stainless steel gas pipe networks, and marine hardware.
310S: Boiler tubes, heat exchangers, and 316 stainless steel pipe systems in power generation.

Factory-Direct Pricing: Eliminate middlemen—competitive rates for 3 inch stainless steel pipe and custom orders.
Certified Quality: ISO 9001, ASTM, and EN compliance, validated by SGS/TUV certifications.
Global Inventory: 10,000+ tons of 316Ti/310S pipes in stock, ready for corrugated stainless steel gas pipe and industrial projects.
Technical Expertise: 25+ years of metallurgical support, including welding guides and corrosion prevention strategies.
Sustainability: 100% recyclable materials with 50+ year lifespans, reducing environmental impact.
