StockSteel

Stainless Steel Pipes | ASTM TP 310S/347H Industrial-Grade Durability

$580.00 SGD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Quantity 1 - 29 tons 30 - 49 tons >= 50 tons

Thickness 1-50mm

Stainless Steel Pipes | ASTM TP 310S/347H Industrial-Grade Durability

Property	ASTM TP 310S	ASTM TP 347H
Material Grade	UNS S31008	UNS S34709
Chemical Composition	24-26% Cr, 19-22% Ni, ≤0.08% C	17-19% Cr, 9-13% Ni, Nb-stabilized
Tensile Strength	515–750 MPa	515–750 MPa
Yield Strength	205 MPa	205 MPa
Hardness (Rockwell B)	95 HRB	192 HBW
Temperature Resistance	Up to 1150°C (continuous)	Up to 871°C (continuous)
Corrosion Resistance	Excellent oxidation resistance	Superior intergranular corrosion resistance
Standard Compliance	ASTM A213, A312, EN 1.4845	ASTM A213, A312, EN 1.4961
Dimensions (OD)	6–2500 mm	6–2500 mm
Wall Thickness	0.5–150 mm	0.5–150 mm
Surface Finish	Annealed, Pickled, Polished	Annealed, Pickled, Polished

High-Temperature Performance
- ASTM TP 310S: Ideal for 3 stainless steel exhaust pipe systems in automotive and aerospace industries, maintaining structural stability up to 1150°C with exceptional creep resistance.
- ASTM TP 347H: Niobium-stabilized composition prevents carbide precipitation, making it suitable for schedule 40 stainless steel pipe applications in power plants and petrochemical reactors.
Mechanical Strength
- Tensile Strength: Both grades withstand extreme stress in high-pressure environments, such as boilers and heat exchangers.
- Bend Strength: TP 347H exhibits superior ductility for forming stainless steel pipe cutter-compatible shapes without cracking.
Corrosion Resistance
- TP 310S: Resists sulfidation and chloride-induced pitting in marine and chemical processing.
- TP 347H: Enhanced resistance to intergranular corrosion in welded components.

The weight of stainless steel pipes is calculated using:
$Weight (kg/m) = \frac{( O D - W T ) \times W T \times 0.02466}{1000}$
Where:

Example: A schedule 40 stainless steel pipe with 100 mm OD and 5 mm wall thickness weighs 11.69 kg/m.

Laser Etching/Stamping: Includes ASTM/EN standards, heat number, and grade (e.g., "TP310S" or "TP347H").
Color Coding: Optional bands for quick identification in industrial settings.

Despite their corrosion-resistant properties, rust can occur due to:

Chloride Exposure: Coastal or de-icing salt environments accelerate pitting in TP 310S.
Intergranular Corrosion: Improper welding of TP 347H without post-weld annealing.
Surface Contamination: Iron particles or grease disrupt the passive chromium oxide layer.
Low-Quality Alloys: Substandard Cr/Ni ratios reduce corrosion resistance.

Premium Material Sourcing: Strict adherence to ASTM/EN standards for 3 stainless steel exhaust pipe, schedule 40 stainless steel pipe, and stainless steel pipe cutter-ready products.
Customization: Tailored dimensions, surface finishes, and certifications (ISO 9001, PED, SGS).
Global Applications: Proven performance in offshore platforms, pharmaceuticals, and aerospace.
Sustainable Choice: 100% recyclable with minimal lifecycle costs.
