Stainless Steel Tube Pipe Sizes | Expert-Crafted Custom Solutions
Stainless Steel Tube Pipe Sizes | Expert-Crafted Custom Solutions
Couldn't load pickup availability
Product Detail Page: Stainless Steel Tube Pipe Sizes | Expert-Crafted Custom Solutions
Technical Specifications & Properties
(Structured Tables for Clarity and SEO Optimization)
1. Dimensional Specifications
| Parameter | Range | Standards |
|---|---|---|
| Outer Diameter (OD) | 6mm – 1200mm | ASTM A312, ASME B36.19, EN 10216 |
| Wall Thickness | 0.5mm – 30mm | Schedule 5S to XXH |
| Length | 1m – 12m (Standard) / Custom Cut Lengths | ISO 1127, ASME SA312 |
| Shape | Round, Square, Rectangular, Oval | ASTM A554, ASTM A269 |
Notes:
- Customizable stainless steel tube pipe sizes are available for specialized projects, including thin-walled (0.4mm) and thick-walled (up to 30mm) designs.
- Tolerance: ±0.1% for precision applications.
2. Material Properties
| Grade | Hardness (HV) | Yield Strength (MPa) | Tensile Strength (MPa) |
|---|---|---|---|
| 304/304L | 170 – 200 | ≥205 | ≥515 |
| 316/316L | 180 – 220 | ≥215 | ≥520 |
| Duplex 2205 | 250 – 290 | ≥450 | ≥620 |
| Super Austenitic | 200 – 240 | ≥240 | ≥550 |
Source: ASTM A312, EN 10088-3.
3. Manufacturing Processes
| Process | Applications | Advantages |
|---|---|---|
| Seamless | High-pressure systems, petrochemicals, boilers | No weld seams; superior corrosion resistance |
| Welded (ERW/EFW) | Structural, decorative, low-pressure fluid transport | Cost-effective; rapid production |
| Cold Rolled | Precision instruments, medical devices | Smooth surface; tight dimensional control |
| Hot Finished | Large-diameter industrial pipelines | High-temperature stability |
Compliance: ASME, PED, TUV, and NACE certifications.
Detailed Technical Descriptions
1. Tensile & Bend Strength
Our stainless steel 304L pipes and tubes are engineered to withstand extreme mechanical stress. The tensile strength (≥515 MPa) ensures durability in high-pressure environments, while bend strength is enhanced through controlled annealing processes. For stainless steel 304 pipes & tubes stockists, we offer Grade 304 with a balanced composition (18% Cr, 8% Ni) for optimal strength-to-weight ratios in construction and machinery.
2. Weight Calculation
Use the formula below to estimate pipe weight per meter:
Weight (kg/m) = (OD – Wall Thickness) × Wall Thickness × 0.02466
Example: A 50mm OD pipe with 2mm wall thickness weighs ≈2.42 kg/m.
3. Identification Marking
All products are laser-etched with:
- Grade (e.g., 304L, 316L)
- Size (OD × Wall Thickness × Length)
- Certification (ASTM/EN Standard, Heat Number)
- Manufacturer Logo
This ensures traceability and compliance with international standards.
4. Causes of Stainless Steel Corrosion
Despite inherent rust resistance, corrosion may occur due to:
- Chloride Exposure: Prolonged contact with seawater or de-icing salts can pit 304-grade steel.
- Intergranular Attack: Low-carbon 304L mitigates this risk in welded joints.
- Galvanic Corrosion: Avoid pairing stainless steel with dissimilar metals in humid environments.
Our 316L pipes (2-3% Mo content) offer enhanced resistance to chlorides and acids.
Why Choose Our Stainless Steel Solutions?
(Positioned at the Bottom for SEO Prioritization of Technical Content)
- Global Stockist Network: As leading stainless steel 304 pipes & tubes stockists, we maintain 10,000+ tons of ready-to-ship inventory across 20+ grades.
- Custom Fabrication: Tailor stainless steel tube pipe sizes to your project’s needs—no minimum order quantity.
- Quality Assurance: Raw materials sourced from top mills (e.g., Tsingshan, Acerinox) with 100% spectrographic testing.
- Fast Delivery: 72-hour dispatch for standard sizes; global logistics partnerships ensure on-time delivery.
- Sustainability: 70% recycled content; ISO 14001-certified production.
