Product Detail Page: Stainless Steel Tube Pipe Sizes | Industrial-Grade ASTM A312 Solutions
Technical Specifications
| Category | Details | Standards |
|---|---|---|
| Material Grades | 316 stainless steel pipe tube, stainless steel 304L pipes and tubes | ASTM A312, EN 10216, JIS G3459 |
| Size Range | Stainless steel tube pipe sizes: 1/8"–48" (DN6–DN1200) | ASME B36.10, DIN 2462 |
| Wall Thickness | 0.5mm–60mm (Schedule 5S to XXS) | ISO 1127, ASTM A999 |
| Length | 6m (Standard), 12m (Extended), Custom Cut-to-Length (±1% Tolerance) | EN 10217, GB/T 14976 |
| Hardness (HRB) | 70–90 (Cold-Drawn), 85–95 (Hot-Rolled) | ISO 6506, ASTM E18 |
| Surface Finish | Mill Finish, Pickled, 180#–600# Polished, Electro-Polished, Hairline | ASTM A480, EN 10088-2 |
| Hollow Section | Round, Square, Rectangular, Oval | ASTM A554, JIS G3463 |
Mechanical & Physical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥515 MPa (304L), ≥550 MPa (316) |
| Yield Strength | ≥205 MPa (304L), ≥290 MPa (316) |
| Elongation | ≥40% (304L), ≥35% (316) |
| Corrosion Resistance | PREN ≥35 (316), Excellent Chloride Resistance |
| Operating Temperature | -200°C to 870°C (304L), -200°C to 925°C (316) |
Key Features & Advantages
Tensile & Bend Strength
Our stainless steel tube pipe sizes are engineered for industrial demands. 316 stainless steel pipe tube offers superior tensile strength (≥550 MPa) due to its molybdenum-enriched alloy (2–3% Mo), making it ideal for high-stress applications like chemical processing and marine environments. The cold-drawn process enhances grain alignment, achieving a 15% higher bend strength compared to hot-rolled alternatives.
Identification & Traceability
Each pipe is laser-etched with:
- Grade Markings (e.g., UNS S31600, S30403)
- Heat Number
- ASTM/EN/JIS Standard Code (e.g., ASTM A312 TP316)
Third-party certifications (TUV, SGS) and Mill Test Reports (MTRs) ensure compliance with stainless steel 304L pipes and tubes specifications.
Weight Calculation
Formula:
Weight (kg/m) = (OD – WT) × WT × 0.02491
Example: A 2" (DN50) Schedule 40S 316 stainless steel pipe tube (OD: 60.3mm, WT: 3.91mm) weighs 5.68 kg/m[(60.3–3.91) × 3.91 × 0.02491].
Corrosion Mechanisms
While stainless steel tube pipe sizes resist rust, localized corrosion can occur due to:
- Chloride Exposure: 304L is vulnerable in seawater; 316’s Mo content prevents pitting.
- Galvanic Coupling: Contact with carbon steel in humid environments accelerates oxidation. Insulating gaskets are recommended.
- Stress Corrosion Cracking (SCC): High chloride + tensile stress (>80°C) may crack 304L. Solution-annealed 316 minimizes this risk.
Applications
- Chemical & Petrochemical: Seamless 316 stainless steel pipe tube for acid transfer (H2SO4, HCl).
- Food & Pharma: Electropolished stainless steel 304L pipes and tubes meet 3-A Sanitary Standards.
- Architectural: Mirror-finished square tubes for handrails and façades.
Why Choose Our Stainless Steel?
- Material Integrity: Our stainless steel tube pipe sizes use prime-grade billets from TISCO and POSCO, ensuring Cr/Ni ratios exceed ASTM minima (18% Cr, 10% Ni for 304L).
- Precision Manufacturing: Cold-drawn (±0.05mm OD tolerance) and hydraulic-expanded tubes for aerospace tolerances.
- Global Compliance: Dual-certified (PED 2014/68/EU + ASME BPV Code) for pressure systems.
- Sustainable Practices: ISO 14001-certified production with 92% recycled content.
- Technical Support: Free lifetime consultation on welding (TIG/MIG), load calculations, and corrosion prevention.
