Superior Stainless Steel Coils | 316L Food Grade & Cold Rolled Excellence
Superior Stainless Steel Coils | 316L Food Grade & Cold Rolled Excellence
Couldn't load pickup availability
Superior Stainless Steel Coils | 316L Food Grade & Cold Rolled Excellence
Product Overview
Our stainless steel coils are engineered for industries demanding exceptional corrosion resistance and structural integrity. Specifically designed for stainless steel coil heat exchanger systems and stainless steel siding nails coil applications, these coils combine 316L’s food-grade compliance with cold-rolled precision. Manufactured under ISO 9001 and CE certifications, they meet ASTM, AISI, and JIS standards, ensuring global reliability in sectors like food processing, chemical engineering, and construction.
Technical Specifications
1. Dimensional & Mechanical Properties
| Parameter | Specification (316L Grade) |
|---|---|
| Thickness | 0.12mm – 20mm (customizable) |
| Width | 900mm – 2200mm (standard or custom) |
| Surface Finish | 2B, BA, NO.4, 8K, Mirror, Hairline |
| Tensile Strength | ≥520 MPa |
| Yield Strength | ≥205 MPa |
| Elongation | ≥40% |
| Hardness (HV) | ≤220 |
| Density | 7.98 g/cm³ |
2. Chemical Composition
| Element | C (%) | Mn (%) | Si (%) | Cr (%) | Ni (%) | Mo (%) |
|---|---|---|---|---|---|---|
| 316L | ≤0.03 | ≤2.00 | ≤1.00 | 16–18 | 10–14 | 2–3 |
Key Features & Applications
1. Cold-Rolled Excellence
Cold-rolled stainless steel coils offer ultra-smooth surfaces (e.g., 2B, BA finishes) with tight tolerances (±1%), ideal for stainless steel coil heat exchanger components requiring minimal friction and high thermal conductivity. This process enhances hardness (≤220 HV) while maintaining ductility for bending and welding.
2. Food-Grade Safety
316L’s low carbon content (≤0.03%) prevents carbide precipitation during welding, making it safe for food processing equipment, dairy tanks, and pharmaceutical machinery. Its molybdenum content (2–3%) resists chlorides in saline or acidic environments.
3. Corrosion Resistance
The chromium oxide layer (Cr ≥16%) provides self-healing protection against oxidation, while molybdenum combats pitting in chloride-rich settings like marine stainless steel siding nails coil applications.
Performance & Durability
1. Tensile & Bend Strength
- Tensile Strength: With ≥520 MPa, these coils withstand high-pressure environments, such as industrial boilers or heat exchangers.
- Bend Strength: The elongation rate (≥40%) ensures flexibility for forming complex shapes without cracking.
2. Weight Calculation
Use the formula:
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × 7.98
Example: A 0.3mm × 1219mm × 2000mm coil weighs ≈5.7 kg/m².
3. Rust Prevention
Despite 316L’s superior corrosion resistance, rust may occur due to:
- Chloride Exposure: Prolonged contact with seawater or de-icing salts.
- Surface Contamination: Iron particles from improper handling tools.
- High-Temperature Oxidation: Continuous use above 427°C (800°F) degrades the passive layer.
Certifications & Customization
- Standards: ASTM A240, AISI 316L, JIS G4303.
- Processing: Custom cutting, decoiling, and edge treatments (slit or mill edge).
- Packaging: PVC film + fumigated wooden frames for international shipping.
Why Choose Our Stainless Steel Coils?
- Global Compliance: ISO, CE, and SGS certifications ensure adherence to food safety and industrial standards.
- Rapid Delivery: 7-day turnaround for bulk orders, backed by 50,000-ton monthly production capacity.
- Custom Solutions: Tailored dimensions (0.12–20mm), finishes, and grades (200/300/400 series).
- Technical Support: 24/7 engineering guidance for stainless steel coil heat exchanger or stainless steel siding nails coil projects.
- Sustainability: Recyclable materials and energy-efficient manufacturing processes.
