Superior Stainless Steel Rod Bar | SUS304 Flat Bar Solutions

$1,190.00 SGD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Quantity 1 - 49 tons 50 - 99 tons 100 - 299 tons >= 300 tons

Dimensions Model Number:A36/1020/45#/Q345/A242/ETC Standard:JIS/AiSi/ASTM/GB/DIN Surface:Natural Color Processing Service:Welding/Decoiling/Punching/Cutting Grade:20CrMo

Quantity

Superior Stainless Steel Rod Bar | SUS304 Flat Bar Solutions

Product Overview

Our stainless steel rod bar and stainless steel round rod bar are engineered to deliver unmatched durability and precision for industrial, architectural, and construction applications. Crafted from premium SUS304/304L grades, these bars combine exceptional corrosion resistance, high tensile strength, and superior surface finishes.

Specifications & Properties

Category	Details
Standard	ASTM A276, ASTM A479, JIS G4303, EN 10088-3
Grades	SUS304, SUS304L, 316/316L, 303 (Custom grades available)
Diameter/Size	Round Bar: 3mm–300mm; Flat Bar: 20mm–150mm (Thickness: 3mm–50mm)
Surface Finish	2B, BA, No.4, HL, No.1, Mirror Polish (Custom finishes on request)
Hardness (HRB)	≤90 (304), ≤90 (304L)
Tensile Strength	520 MPa (304), 480 MPa (304L)
Yield Strength	205 MPa (304), 175 MPa (304L)
Elongation	≥40%
MOQ	1 Ton

Key Features

1. Tensile & Bend Strength

Our stainless steel rod bar excels in mechanical performance. The tensile strength of SUS304 (520 MPa) ensures resistance to deformation under heavy loads, while its yield strength (205 MPa) guarantees structural integrity in dynamic environments. For bend strength, the formula $σ_{b} = \frac{M \cdot y}{I}$ applies, where $M$ is bending moment, $y$ is distance from the neutral axis, and $I$ is the moment of inertia. Our bars are tested to withstand bending angles up to 180° without cracking, making them ideal for architectural frameworks and machinery components.

2. Corrosion Resistance

The chromium-nickel alloy in SUS304 forms a passive oxide layer, preventing oxidation. However, stainless steel rust can occur due to:

Chloride exposure (e.g., coastal environments).
Mechanical damage (scratches or abrasions).
Contaminants (organic acids, salts).
Our china stainless steel rod bar uses 304L (low carbon) for enhanced weldability and reduced sensitization in corrosive settings.

3. Weight Calculation

Weight per meter (kg/m) for stainless steel round rod bar:
$Weight = \frac{π \times D ^{2}}{4} \times 7.93 (density in g/cm^{3}) \times 0.001$
For flat bars:
$Weight = Width \times Thickness \times 7.93 \times 0.001$

4. Identification & Marking

Bars are laser-marked with:

Grade (e.g., SUS304, 316L).
Batch number.
Standard compliance (ASTM, JIS, EN).
Certifications include Mill Test Reports (MTRs) and ISO 9001 compliance.

Processing Capabilities

Cutting: Precision sawing to custom lengths (12' standard).
Polishing: Mirror, hairline, or brushed finishes.
Heat Treatment: Solution annealing for stress relief.
Custom Fabrication: CNC machining, bending, and welding.

Applications

Construction: Beams, fasteners, and support structures.
Marine: Shipbuilding components resistant to saltwater.
Food Processing: Hygienic equipment with BA/2B finishes.
Automotive: Exhaust systems and engine parts.

Why Choose Our Stainless Steel Rod Bar?

Premium Material: Strict adherence to ASTM/JIS standards with 18-20% Cr and 8-11% Ni.
Custom Solutions: Tailored sizes, grades (e.g., 316L for chloride resistance), and finishes.
Quality Assurance: Rigorous testing for hardness, tensile strength, and corrosion resistance.
Global Compliance: Certified for EU, US, and Asian markets.
Sustainable Manufacturing: Eco-friendly processes with minimal waste.

As a leading china stainless steel rod bar supplier, we ensure on-time delivery, competitive pricing, and technical support. Partner with us for projects demanding reliability and excellence.
