StockSteel

Trusted Stainless Steel Pipes Supplier | JIS/EN/ASIS Certified

Trusted Stainless Steel Pipes Supplier | JIS/EN/ASIS Certified

$1,860.00 SGD
$1,860.00 SGD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity
Thickness

​Trusted Stainless Steel Pipes Supplier | JIS/EN/ASIS Certified Product Details

​1. Specifications

Comprehensive specifications of ​stainless steel pipes are designed to meet industrial demands, adhering to JIS, EN, ASME, and ASTM standards.



Parameter Details
​Standards JIS G3459, EN 10216, ASME B36.19, ASTM A312/A269/A789
​Material 201, 304, 304L, 316, 316L, 321H, 409L, 904L, SUS315J1TP, SUS890LTP
​Outer Diameter 6–630 mm (seamless), 2–550 mm (welded)
​Thickness 1–40 mm (cold/hot rolled), 1.5–65 mm (seamless)
​Length 2–12 meters (customizable)
​Process Seamless (hot extrusion/cold drawing), Welded (ERW/TIG)
​Surface Finish Polished, 2B, BA, Pickling, Hairline, Beveled Ends
​Certification ISO 9001, SGS, TUV, EN10204 3.1/3.2

​2. Hardness & Mechanical Properties

Our ​stainless steel pipes exhibit superior mechanical performance, validated by third-party testing.

Grade Hardness (HV) Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
​304/304L 150–200 520–750 205–310 ≥35
​316/316L 160–220 530–770 210–320 ≥35
​SUS315J1TP 170–230 ≥520 ≥205 ≥35
6
​SUS890LTP 180–240 ≥490 ≥215 ≥35
7

​3. Dimensions & Attributes

Designed for versatility, our ​stainless steel pipes cater to high-pressure, corrosive, and structural applications.

Attribute Description
​OD Range 2–630 mm (welded), 3–508 mm (seamless)
​Wall Thickness Ultra-thin (1 mm) to ultra-thick (65 mm)
​Length Options Fixed (6m/12m) or custom-cut (2–12m)
​Applications Pressure vessels, boilers, heat exchangers, structural supports, marine environments

​4. Manufacturing Process

Advanced techniques ensure precision and durability for ​stainless steel pipes.

Process Key Features
​Seamless Hot extrusion/cold drawing; No welds; Uniform wall thickness
​Welded ERW/TIG welding; High corrosion resistance; Cost-effective
​Surface Treatment Polishing (mirror/HL/BA), pickling (oxide removal), beveling (for welding)
​Quality Control Eddy current, hydraulic pressure, and ultrasonic testing

​Detailed Technical Descriptions

​Tensile & Bend Strength

Our ​stainless steel pipes are engineered for high tensile strength (520–770 MPa) and bend resistance, ensuring structural integrity under extreme loads. For example, SUS890LTP pipes achieve ≥490 MPa tensile strength, ideal for high-temperature boilers. The bend strength is enhanced by cold-working processes (e.g., cold rolling), which refine grain structures and reduce brittleness.

​Identification Methods

Pipes are marked with laser engraving or embossing, including:

  • ​Grade (e.g., 304, SUS315J1TP)
  • ​Standard (e.g., JIS G3459, ASTM A312)
  • ​Size (OD × thickness × length)
  • ​Manufacturer Code (e.g., TJC Steel, Zhstainlesspipe)

​Weight Calculation Formula

Calculate pipe weight (kg/m) using:
Weight = (OD - Thickness) × Thickness × 0.02491
Example: For a 114.3 mm OD × 6 mm thickness 304 pipe:
(114.3 - 6) × 6 × 0.02491 = ​16.2 kg/m

​Why Stainless Steel Pipes Rust?

Despite corrosion resistance, ​stainless steel pipes may rust due to:

  1. ​Chloride Exposure (e.g., marine environments).
  2. ​Intergranular Corrosion (improper welding or heat treatment).
  3. ​Surface Contamination (iron particles or grease).
  4. ​Low Chromium Content (grades like 409L are less resistant).
    Prevent rust by using ​stainless steel pipe clamps (isolate galvanic corrosion) and selecting higher grades (316L/904L).

​Why Choose Our Stainless Steel Pipes?

  1. ​Certified Excellence
    Compliant with JIS, EN, ASME, and ISO standards.

    Third-party inspections (SGS, TUV) ensure traceability.

  2. ​Global Supplier Network
    As leading ​stainless steel pipe suppliers, we serve industries in 50+ countries with warehouses in Wenzhou, Jiangsu, and Johor.

  3. ​Technical Expertise
    Over 20 years of experience in producing ultra-thin/thick pipes for heat exchangers and superheaters.

  4. ​Custom Solutions
    Tailor-made sizes, finishes, and certifications (e.g., EN10204 3.2）.

  5. ​Logistics Assurance
    Fast global shipping with secure packaging (wooden cases/bundles).

View full details
