Ultimate 430 Stainless Steel Coil | Mirror Finish & Cold Rolled
Product Overview
The ultimate 430 Stainless Steel Coil is a premium-grade ferritic stainless steel solution designed for demanding industrial and architectural applications. With its exceptional corrosion resistance, mirror finish, and cold-rolled precision, this coil is ideal for projects requiring durability, aesthetic appeal, and structural integrity. Whether used for stainless steel coil siding nails, automotive components, or architectural cladding, this product delivers unmatched performance.
Specifications
| Property | Details |
|---|---|
| Thickness | 0.02mm–10mm (Cold Rolled: 0.02mm–3.0mm; Hot Rolled: 3.0mm–10mm) |
| Width | 3.5mm–1550mm (Customizable Slit Edges Available) |
| Surface Finish | 2B, BA, No.4 (Matte Polished), Mirror, HL (Hairline), 8K |
| Hardness | ≤183 HB (Rockwell B ≤88) |
| Density | 7.7 g/cm³ |
| Melting Point | 1427°C |
| Coefficient of Expansion | 10.4 μm/m·°C (20–100°C) |
| Certifications | ASTM A240, JIS G4304, DIN 17441, SGS, BV |
Mechanical & Chemical Properties
Tensile Strength
The ultimate 430 Stainless Steel Coil boasts a tensile strength (σb) of ≥450 MPa, ensuring excellent resistance to deformation under heavy loads. This makes it suitable for structural applications like coiled stainless steel roofing and industrial machinery components.
Yield Strength
With a minimum yield strength (σ0.2) of ≥205 MPa, the coil maintains structural integrity even under prolonged stress, making it ideal for stainless steel siding nails coil and automotive trim.
Elongation & Formability
The elongation rate (δ5) of ≥22% allows for superior formability, enabling complex shaping without cracking. This property is critical for applications requiring precision bends, such as HVAC systems and kitchen equipment.
Weight Calculation
To calculate the weight of a coiled stainless steel sheet:
Weight (kg) = Thickness (mm) × Width (mm) × Length (m) × Density (7.7 g/cm³) ÷ 1000
Example: For a 1.5mm × 1219mm × 50m coil:
1.5 × 1219 × 50 × 7.7 ÷ 1000 = 703.3 kg
Why Does Stainless Steel Rust?
While 430 stainless steel is highly corrosion-resistant, rust can occur under extreme conditions:
- Chloride Exposure: Prolonged contact with saltwater or de-icing chemicals can degrade the passive chromium oxide layer.
- Mechanical Damage: Scratches or abrasions expose the underlying metal to oxidation.
- High Humidity: Combined with acidic pollutants, moisture accelerates pitting corrosion.
Regular cleaning and avoiding harsh environments can mitigate these risks.
Identification & Marking
Our coils are marked with:
- Grade: 430
- Standard: ASTM A240 / JIS G4304
- Batch Number: Traceable via MTC (Mill Test Certificate)
- Surface Finish Code: e.g., 2B, BA, No.4
Applications
- Architectural Cladding: Ideal for stainless steel coil siding nails due to its weather resistance.
- Automotive Parts: Exhaust systems, trim, and decorative elements.
- Kitchen Equipment: Sinks, countertops, and appliances.
- Industrial Machinery: Heat exchangers and fuel burner components.
Why Choose Our Stainless Steel Coils?
- Premium Material: Sourced from TISCO and BAOSTEEL, ensuring consistent quality.
- Customization: Available in slit edges, custom widths, and multiple finishes (Mirror, HL, No.4).
- Certified Durability: Compliant with ASTM, DIN, and JIS standards.
- Global Logistics: Fast shipping (3–15 days) and seaworthy packaging.
- Technical Support: Expert guidance on weight calculation, fabrication, and corrosion prevention.
