Ultimate Stainless Steel Coils | Hairline & AISI 201/410 for High-Performance
Ultimate Stainless Steel Coils | Hairline & AISI 201/410 for High-Performance
Couldn't load pickup availability
Ultimate Stainless Steel Coils | Hairline & AISI 201/410 for High-Performance
Product Specifications
| Property | AISI 201 | AISI 410 | Hairline Finish |
|---|---|---|---|
| Thickness | 0.4mm – 6.0mm | 0.4mm – 40mm | 0.4mm – 3.0mm |
| Width | 20mm – 1500mm | 20mm – 1500mm | 20mm – 1000mm |
| Hardness | 1/4 Hard, 1/2 Hard, Full Hard | 1/2 Hard, Full Hard | 1/4 Hard, 1/2 Hard |
| Surface Finish | 2B, Bright, Polished | 2B, Cold Rolled, Annealed | Hairline (Linear Brushed) |
| Tensile Strength | 700–850 MPa | 450–650 MPa | 650–800 MPa |
| Yield Strength | 260–310 MPa | 345–550 MPa | 275–350 MPa |
| Elongation | 40% – 55% | 20% – 30% | 30% – 45% |
| Applications | Stainless steel pipe coil, architectural cladding, automotive | Stainless steel heating coil, industrial machinery, fasteners | Decorative panels, stainless steel coil siding nails, high-end appliances |
Key Attributes & Performance
Tensile & Bend Strength
AISI 201 offers exceptional tensile strength (700–850 MPa) due to its high manganese and nitrogen content, making it ideal for structural applications like stainless steel pipe coil systems. Its superior ductility (40–55% elongation) ensures resistance to cracking during cold forming. AISI 410, with moderate tensile strength (450–650 MPa), excels in high-stress environments such as stainless steel heating coil units, where thermal cycling and mechanical wear are common. The Hairline Finish variant combines aesthetic appeal with functional durability, achieving 650–800 MPa tensile strength for applications like stainless steel coil siding nails and architectural accents.
Weight Calculation
The weight of a stainless steel coil can be calculated using the formula:
Weight (kg) = Thickness (mm) × Width (m) × Length (m) × Density (7.93 g/cm³)
For example, a 0.4mm × 1000mm × 2000mm coil weighs approximately 6.34 kg. Advanced tools like the BS Stainless Coil Calculator simplify this process, ensuring precision for custom orders.
Why Stainless Steel Rusts
While stainless steel is inherently corrosion-resistant, improper handling or environmental factors can lead to surface oxidation. Common causes include:
- Chloride Exposure: Saltwater or de-icing agents degrade the chromium oxide layer.
- Mechanical Damage: Scratches or abrasions expose raw metal to moisture.
- Low-Quality Alloys: Substandard chromium/nickel ratios reduce corrosion resistance.
Our coils, crafted with ≥10.5% chromium and optimized nickel/molybdenum ratios, mitigate these risks through passivation treatments and rigorous quality checks.
Identification & Marking
Each coil is laser-etched with:
- Grade (AISI 201/410)
- Batch Number (for traceability)
- Surface Finish (e.g., 2B, Hairline)
- Dimensions (thickness/width/length)
Certifications (ISO 9001, ASTM A666) and third-party inspection reports (SGS) ensure compliance with global standards.
Why Choose Our Stainless Steel Coils?
- Premium Material Integrity:
- AISI 201/410 grades sourced directly from certified mills like Tisco and Baosteel.
- Hairline Finish coils undergo precision cold-rolling and electrochemical polishing for uniform texture.
- Technical Superiority:
- Customized solutions for stainless steel pipe coil, heating coil, and siding nails, with tolerance as tight as ±0.01mm.
- Advanced anti-rust treatments, validated by 94.3% corrosion inhibition efficiency in HCl environments.
- Global Compliance:
- Meets ASTM, EN, JIS, and GB standards for aerospace, chemical, and construction sectors.
- Full material traceability via QR codes and mill test reports.
- Sustainable Production:
- Recyclable coils with ≤0.03% carbon footprint reduction through energy-efficient cold-rolling.
- Unmatched Support:
- 24/7 technical guidance, including coil weight/length calculators and CAD design services.
