UltraShield Stainless Steel Plate Grades | 201/304/316L

UltraShield Stainless Steel Plate Grades | 201/304/316L

$1,330.00 SGD
$1,330.00 SGD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Quantity

UltraShield Stainless Steel Plate Grades | 201/304/316L

Technical Specifications

Property Grade 201 Grade 304 Grade 316L
Thickness (mm) 0.3–6.0 (±0.05) 0.3–100 (±0.05) 0.5–100 (±0.05)
Width × Length 1000–2000mm × 2000–6000mm 1000–2000mm × 2000–6000mm 1000–2000mm × 2000–6000mm
Hardness (HV) 200–250 170–220 215–260
Tensile Strength 750–950 MPa 515–720 MPa 520–670 MPa
Yield Strength 450–650 MPa 205–310 MPa 240–290 MPa
Surface Finish 2B, BA, No.4, Mirror 2B, HL, Satin Electropolished, No.4

Certifications: ASTM A240/A480, EN 10088-2, JIS G4304, ISO 9001, FDA 21 CFR 175.300.



Key Properties & Performance

Tensile & Bending Strength

Our stainless steel plate grades are engineered for diverse industrial demands:

  • Grade 201: With high manganese content, it achieves tensile strength up to 950 MPa, ideal for structural components in automotive trim and railcar interiors.
  • Grade 304: Balances ductility (40% elongation) and strength (515–720 MPa), perfect for stainless steel sushi and dip plate manufacturing due to its hygienic surface and resistance to acidic foods.
  • Grade 316L: Enhanced with 2–3% molybdenum, it withstands chloride-rich environments (e.g., marine applications) while maintaining bending radii as low as 1.5× thickness.

Corrosion Resistance

Chromium oxide layers (16–18% Cr) prevent rust, but exceptions occur due to:

  1. Chloride Exposure: Grade 304 may pit in coastal areas; Grade 316L’s molybdenum mitigates this risk.
  2. Mechanical Damage: Scratches from abrasive tools compromise the passive layer. Our avanchy stainless steel plate uses electropolishing (Ra ≤0.1µm) to reduce surface flaws.
  3. Poor Welding: Improper techniques (e.g., carbon steel contamination) trigger intergranular corrosion. Laser welding ensures Grade 316L’s weld integrity.

Weight Calculation

Formula for precision:

Example: A 1.5×3m Grade 304 plate (2mm thick) weighs .

Identification & Traceability

Each plate is laser-marked with:

  • Grade designation (e.g., 316L)
  • Heat number for batch tracking
  • Compliance marks (ASTM/EN/JIS).

Manufacturing Excellence

Process Description
Cold Rolling Achieves mirror finishes (Ra ≤0.05µm) for stainless steel sushi and dip plate hygiene.
Laser Cutting ±0.1mm precision for custom avanchy stainless steel plate designs in architectural cladding.
Passivation Nitric acid treatment removes iron contaminants, boosting corrosion resistance by 30%.

Applications

  • Food & Beverage: Grade 304 for FDA-compliant stainless steel sushi and dip plate and brewery tanks.
  • Marine Engineering: Grade 316L sheets for desalination plants and ship hulls.
  • Consumer Goods: Avanchy stainless steel plate in premium cookware and medical equipment.

Why Choose Our Stainless Steel Plates?

  1. Global Compliance: Certified for ASTM, EN, and JIS standards, ensuring material traceability and quality assurance.
  2. Customization: Tailored dimensions (e.g., 1500×3000mm) and finishes (No.4, Mirror) for niche applications like avanchy stainless steel plate manufacturing.
  3. Rapid Delivery: 10,000+ tons in stock, ready for same-day dispatch with anti-scratch PVC packaging.
  4. Sustainability: 100% recyclable with ISO 14001-certified production, reducing carbon footprint by 50%.
  5. Technical Support: 24/7 engineering guidance on welding, corrosion prevention, and design optimization.
