Versatile Stainless Steel Square Bar Rod – DIY & Industrial Use
Versatile Stainless Steel Square Bar Rod – DIY & Industrial Use
Couldn't load pickup availability
Versatile Stainless Steel Square Bar Rod – DIY & Industrial Use
Technical Specifications
Material Grades & Dimensions
| Grade | Cross-Section (mm) | Length (m) | Surface Finish | Hardness (HRB) | Applications |
|---|---|---|---|---|---|
| 201 | 5×5–100×100 | 1–6 | Brushed | ≤100 | Stainless steel square bar rod for decorative railings, furniture, and lightweight structures |
| 304 | 10×10–200×200 | 1–12 | Mirror/Satin | ≤90 | Industrial frameworks, HVAC systems, and marine hardware |
| 316 | 20×20–150×150 | 1–12 | Polished | ≤95 | Chemical plants, coastal architecture, and high-temperature environments |
Mechanical Properties
| Property | 201 (MPa) | 304 (MPa) | 316 (MPa) |
|---|---|---|---|
| Tensile Strength | ≥520 | ≥520 | ≥515 |
| Yield Strength | ≥275 | ≥205 | ≥205 |
| Elongation (%) | ≥45 | ≥40 | ≥40 |
Detailed Technical Insights
Tensile & Bending Strength
Stainless steel square bar rod excels in both tensile and bending strength, making it ideal for load-bearing structures. Grade 304, with a tensile strength of ≥520 MPa, is widely used in industrial frameworks where resistance to deformation is critical. Its high ductility (≥40% elongation) allows for cold bending and welding without cracking.
For variety stainless steel round rods bar for DIY craft, Grade 201 offers a balance of affordability and strength (≥520 MPa tensile strength), suitable for decorative projects like garden sculptures or custom furniture. Grade 316, enhanced with 2–3% molybdenum, maintains structural integrity even in chloride-rich environments like coastal areas.
Weight Calculation
Use the formula to estimate the weight of stainless steel round bar steel rod:
For a round rod:
Example: A 10mm diameter × 1m rod weighs 0.63 kg (density = 7.93 g/cm³).
Identification & Marking
- Laser Etching: Permanent markings include ASTM grade (e.g., "304"), manufacturer code, and batch number.
- Color Coding: Red for 201, blue for 304, and yellow for 316 to simplify inventory management.
Why Stainless Steel Rusts
While stainless steel is corrosion-resistant, rust can occur under specific conditions:
- Chloride Exposure: Coastal or industrial environments degrade the passive chromium oxide layer. Grade 316 mitigates this risk due to its molybdenum content.
- Mechanical Damage: Scratches during fabrication expose raw steel. Always use nylon tools and protective films during handling.
- Galvanic Corrosion: Contact with carbon steel or aluminum in moist environments. Insulate metals with dielectric barriers.
- Low Chromium Content: Grade 201 (16% Cr) is less resistant than Grade 304 (18% Cr).
Applications of Stainless Steel Square Bar Rod
- DIY Crafts: Variety stainless steel round rods bar for DIY craft projects, including jewelry, wall art, and tool handles.
- Construction: Stainless steel round bar steel rod for structural beams, stair railings, and seismic reinforcements.
- Marine Engineering: Grade 316 rods for boat fittings, dock hardware, and offshore platforms.
- Industrial Machinery: High-strength 304 square bars for conveyor systems, hydraulic components, and tooling fixtures.
Why Choose Our Stainless Steel Products?
- Certified Excellence: Compliant with ASTM A484, ASME SA276, and ISO 9001 standards.
- Custom Solutions: Tailored dimensions (5×5mm to 200×200mm), surface finishes (brushed/mirror), and bulk discounts.
- Rapid Delivery: 10,000+ tons of stainless steel square bar rod in stock for same-day shipping.
- Global Reach: Strategically located near Shanghai Port, serving clients in the EU, North America, and ASEAN.
- Sustainability: 100% recyclable materials with a 30% reduced carbon footprint compared to conventional steel.
